The bottom status bar displays some information on the system status.
2a - Operating mode
2b - System status
Operating mode (2a) is controlled by the lockable selector.
System status (2b) displays part of the information on page S.01 (STATUS) which is useful for the operator, as it
can be displayed also if other pages are being viewed and in other display modes.
In some pages, pressing the SHIFT
down with a HELP message. If the message is unavailable, the bar is cleared and restored when the button is
released.
WARNING: The parameters must only be changed by qualified personnel. Assigning an
incorrect value to one or more parameters can cause malfunctions, damage to things and/or
injury to people.
Information!: Parameters may be password protected
This mode lets you display and change the programming parameters.
Each programming parameter has a 4-digit numeric code (ex. P.0101) to identify the variables regardless of
the language used.
The first line under the top status bar identifies the current menu with the menu number and the relevant text.
A pair of numbers are displayed on the right in this line.
The first indicates which entry in the menu is selected or which page is displayed, the seconds indicates how
many entries or pages can be displayed in the current menu/submenu.
DST4602Evolution User's Manual
12
OFF
2a
Fig. 5 - Bottom status bar
|Engine stopped
2b
button replaces the bottom status bar for the time the button is held
-
