Technical data
Material
Tolerance of probe length
Weight
86
10.1.6 Mechanical construction
See TI00386F/00/EN, chapter "Material (not in contact with process)" and "Material (in contact
with process)".
over (m / ft)
up to (m / ft) 1 (3.2)
admissible toler- - 5
ance (mm / inch) (- 0.2)
Levelflex M
Weight for the F12 or T12 housing
Weight for the F23 housing
Rod probes
1 (3.2) 3 (9.8) 6 (20 )
3 (9.8 ) 6 (20)
- 10 - 20 - 30
- 0.4) (- 0.8) (- 1.2)
FMP41C + rod probe
approx. 3.5 kg + approx. 1.1 kg/m
Probe length + Flange weight
approx. 6.8 kg + approx. 1.1 kg/m
Probe length + Flange weight
Levelflex M FMP41C PROFIBUS PA
Rope probes
1 (3.2) 3 (9.8)
1 (3.2) 3 (9.8 ) 6 (20)
- 10 - 20 - 30
(- 0.4) (- 0.8) (- 1.2)
FMP41C + rope probe
approx. 3.5 kg + approx. 0.5 kg/m
Probe length + Flange weight
approx. 6.8 kg + approx. 0.5 kg/m
Probe length + Flange weight
Endress+Hauser
6 (20 )
- 40
(- 1.6)
