Table 2: Pinout of Connector J1 (Continued)
Pin Label
35 GFAULT.W
36 GFAULT.Z
37 GFAULT.B
38 GND
39 GND
40 GND

3.3.2 Power Interface

Description of the power terminals are provided in
Table 3: Power Interface, Connectors Description
Label
+DC_BUS
-DC_BUS
N_REC
BRAKE
L1, L2, L3
U, V, W
0 V, 24 V

3.4 Mechanical Data

Table 4 provides a complete list of the mechanical data.
Table 4: Mechanical Data of the EB1200-352J
Description
Number of layers
PCB copper thickness
PCB Insulating material
Board weight without PIM
Board length
Board width
Board height
PCB thickness
Broadcom
GFAULT signal for high-side power switch in phase W
GFAULT signal for low-side power switch in phase B
Fault signal for brake power switch
Ground
Ground
Ground
Connector Description
DC bus positive rail input
DC bus negative rail input
Negative diode rectifier output rail
Brake chopper IGBT – collector
Diode rectifier phase inputs
Inverter phases
Isolated power supply input for digital circuitry
Value
4
70 µm – top and bottom layer
35 µm – inner layers
FR4
610 g
292 mm
217 mm
48.6 mm
1.6 mm
Infineon EconoPIM™ 3 IGBT Module EB1200-352J Evaluation Board
Function
Table 3.
Direction
Output
Output
Output
Bidirectional
Bidirectional
Bidirectional
Value
M4 screw terminal
PCB screw terminal
PM5.08/2/90, 26 AWG, 14 AWG
ACPL-352J-EB1200-RM100
