Chapter 6: Typical Switching and DESAT Protection
Characteristics

6.1 Typical Switching Losses

Because the EB1200-352J has integrated a DC bus capacitor bank, the worst-case commutation inductance (measured for
the switch with the longest path to the DC bus capacitors) is a constant 67 nH and does not vary from the setup used to
characterize switching characteristic.
As an example, Figure 17
Figure 17: (a) Turn-On (E
EB1200-352J: typical turn-on energy loss at 600V
6
5
4
3
2
0.597
1
0
0 10
EB1200-352J: typical turn-o energy loss at 600V
7
6
5
4
3
2
1.02
1
0
0 10
Broadcom
shows the obtained turn-on and turn-off losses at 25°C for PIM FP75R06KT4.
) and (b) Turn-Off (E ) Switching Energy
on off
2.32
1.61
1.07
20 30 40
Ic [A]
(a)
4.25
3.5
2.67
1.9
20 30 40
Ic [A]
(b)
5.63
5.02
4.04
3.12
50 60 70
6.11
5.81
5.02
50 60 70
Infineon EconoPIM™ 3 IGBT Module EB1200-352J Evaluation Board
80
