ACPL-337J Reference Manual

3.3.2 Power Interface

Description of the power terminals are provided in
Table 3: Power Interface, Connectors Description
Label
+DC_BUS
-DC_BUS
N_REC
BRAKE
L1, L2, L3
U, V, W
0 V, 24 V

3.4 Mechanical Data

Table 4 provides a complete list of the mechanical data.
Table 4: Mechanical Data of the EB600-337J
Description
Number of layers
PCB copper thickness
PCB Insulating material
Board weight without PIM
Board length
Board width
Board height
PCB thickness
Broadcom
Connector Description
DC bus positive rail input
DC bus negative rail input
Negative diode rectifier output rail
Brake chopper IGBT – collector
Diode rectifier phase inputs
Inverter phases
Isolated power supply input for digital circuitry
Value
4
70 µm – top and bottom layer
35 µm – inner layers
FR4
370 g
225 mm
185 mm
48.6 mm
1.6 mm
Table 3.
Infineon EasyPIM™ 1B IGBT Module EB600-337J Evaluation Board
M4 screw terminal
PCB screw terminal
PM5.08/2/90, 26 AWG, 14 AWG
Value
ACPL-337J-EB600-RM100
