3.3 Pin Assignments

This section describes the pin assignments of signal and power interface on the EB1200-352J. Part numbers and
mechanical details of each connector can be found using manufacturer part numbers provided in

3.3.1 Signal Interface

Table 2 shows pin assignment for the signal connector J1. The schematic and layout of this connector are shown in
Appendix A, Schematics, Layout, and
Table 2: Pinout of Connector J1
Pin Label
1 PWM.U
2 PWM.X
3 PWM.V
4 PWM.Y
5 PWM.W
6 PWM.Z
7 PWM.B
8 GND
9 GND
10 GND
11 GND
12 GND
13 FAULT.B
14 UVLO.B
15 FAULT.W
16 UVLO.W
17 FAULT.V
18 UVLO.V
19 FAULT.U
20 UVLO.U
21 FAULT.X
22 UVLO.X
23 FAULT.Y
24 UVLO.Y
25 FAULT.Z
26 UVLO.Z
27 GND
28 GND
29 GND
30 TEMP
31 GFAULT.U
32 GFAULT.X
33 GFAULT.V
34 GFAULT.Y
Broadcom
BOM.
PWM signal for high-side power switch in phase U
PWM signal for low-side power switch in phase U
PWM signal for high-side power switch in phase V
PWM signal for low-side power switch in phase V
PWM signal for high-side power switch in phase W
PWM signal for low-side power switch in phase W
PWM signal for brake power switch
Ground
Ground
Ground
Ground
Ground
Fault signal for brake power switch
UVLO signal for brake power switch
UVLO signal for high-side power switch in phase W
Fault signal for high side power switch in phase W
UVLO signal for high-side power switch in phase V
Fault signal for high-side power switch in phase V
UVLO signal for high-side power switch in phase U
Fault signal for high-side power switch in phase U
UVLO signal for low-side power switch in phase U
Fault signal for low side power switch in phase U
UVLO signal for low-side power switch in phase V
Fault signal for low-side power switch in phase V
UVLO signal for low-side power switch in phase W
Fault signal for low side power switch in phase W
Ground
Ground
Ground
Isolated temperature measurement signal
GFAULT signal for high-side power switch in phase U
GFAULT signal for low-side power switch in phase U
GFAULT signal for high-side power switch in phase V
GFAULT signal for low-side power switch in phase V
Infineon EconoPIM™ 3 IGBT Module EB1200-352J Evaluation Board
Function
Section A.3, BOM.
Direction
Input
Input
Input
Input
Input
Input
Input
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Bidirectional
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Output
Bidirectional
Bidirectional
Bidirectional
Output
Output
Output
Output
Output
