Optex Smart Line SL-100 TNR Installation Instructions page 4

5-2 OPERATION CHECK
After installation is complete, be sure to check the operation.
Make sure that the Alarm/Level indicator LED is OFF.
1
If it is illuminated even when the beams are not blocked, make optical
alignment again.
Check that the Power/Low battery indicator LEDs on both transmitter and
2
receiver are ON.
If the Power/Low battery indicator LED is blinking, the battery power is low.
Replace with new batteries.
3 Conduct a walk test to check that Alarm/Level indicator LED on the
receiver turns ON as the walker interrupts the beams.
6
TROUBLESHOOTING
PROBLEM
Power/Low battery indicator LEDs are
not illuminated. (transmitter/receiver)
Alarm is not output.
When the beam is blocked, the
"ALARM" indicator LED is illuminated
but the alarm is not activated.
Alarm is activated even if the
light is not blocked.
Batteries are running out too quickly.
Frost, snow or heavy rain
causes false alarm.
Improper output
Even if new batteries are used, Low
battery indicator LED is ON.
8
SPECIFICATIONS
Model
Maximum detection range
Maximum arrival distance
Detection method
Interruption time
Power source
3.9 VDC
Current draw
(stand by /at 25°C)
3.0 VDC
Transmitter
SB-D02HP
by VITZROCELL
Battery
Receiver
life
Transmitter
CRH-5 (CR123A
*
**
by Panasonic)
Receiver
Alarm output
Alarm period
Output
Low battery output
Cover tamper output
(Receiver)
Alarm/ Level indicator
(Receiver)
Indicator
LED
Power/ Low battery indicator
(Transmitter and Receiver)
Operating temperature
Operating humidity
Alignment angle
Dimension
Weight
International protection
Specifications and design are subject to change without prior notice.
* The value is based on the condition that it is used within the ambient temperature range of 20 to 25°C.
** Using batteries other than those recommended may shorten the battery life.
OPTEX CO., LTD. (JAPAN)
URL: http://www.optex.net/
POSSIBLE CAUSE CORRECTIVE ACTION
Reversed battery polarity. Check the battery polarity.
Reflection from the floor or wall. Align beams away from the floor or wall.
Beam has not been blocked. Block all two beams.
Signal line short-circuited Check the wiring.
See "4-1 BEAM INTERRUPTION
Interruption time is too short. ADJUSTMENT" on page 3, set an
appropriate interruption time.
Surface of
Clean the cover (wipe the cover with
Transmitter/Receiver cover
a soft cloth dampened with water or
soiled.
diluted neutral detergent).
Optical alignment was not See "4-2 OPTICAL ALIGNMENT" on
performed properly. page 3 and make realignment.
Problem with tamper output. Set the cover properly.
See "4-2 OPTICAL ALIGNMENT"
Optical alignment not optimized.
on page 3 and make realignment.
Problem with wiring. Install the correct wiring.
Open and close the battery cover
20 times with two seconds intervals.
Batteries are inactive condition.
After this, open the battery plate
and then close it.
SL-100TNR
30 m/100 ft. 60 m/200 ft.
265 m/800 ft. 530 m/1740 ft.
Twin infrared beam interruption detection
Variable between 50/100/250/500 ms (4 steps)
3.9 VDC D size lithium batteries Each Transmitter and Receiver: 2 units
(SB-D02HP manufactured by VITZROCELL)
3.0 VDC CR123A lithium batteries Each Transmitter and Receiver: 8 units
(OPTION CRH-5: 2unit)
Total: Approx. 500 μA Total:
Transmitter: Approx. 200 μA Transmitter: Approx. 300 μA
Receiver: Approx. 300 μA Receiver:
Total: Approx. 600 μA Total:
Transmitter: Approx. 200 μA Transmitter: Approx. 300 μA
Receiver: Approx. 400 μA Receiver:
Approx. 6 years Approx. 5 years
Approx. 5 years Approx. 5 years
Approx. 1.5 years Approx. 1 year
Approx. 1 year Approx. 1 year
Form C-Solid State Switch: 3.9 VDC, 0.01 A
2 s (±1)
N.C. (Solid State Switch): 3.9 VDC, 0.01 A
N.C. (Solid State Switch): 3.9 VDC, 0.01 A
Opens when the battery cover removed.
ON: Beam not received
Blinking: Beam not received sufficiently
OFF: Beam received
ON: Power ON
Blinking: Voltage reduction
OFF: Power OFF
-20°C to +60°C (-4°F to 140°F)
95 % (max.)
±90° Horizontal, ±5° Vertical
H × W × D mm (inch): 295 (11.6) × 69 (2.7) × 117 (4.6)
1200 g (Total weight of Transmitter + Receiver, excluding accessories)
IP65
OPTEX INC. (U.S.)
www.optexamerica.com
OPTEX DO BRASIL LTDA. (Brazil)
www.optex.net/br/es/sec
OPTEX (EUROPE) LTD. / EMEA HQ (U.K.)
www.optex-europe.com
Transmitter Receiver
A B
C
7
DIMENSIONS
9
OPTIONS
SL-200TNR
BCU-5 Battery Common use Unit (2 units/set)
Share power source and low battery signals between the main unit and the wireless
transmitter.
Approx. 600 μA
Approx. 300 μA
Approx. 700 μA
CRH-5 CR123A Battery Holder (2 units/set)
Approx. 400 μA
Battery holder when using CR123A as a power source
PCU-5 Power Convertor Unit (1 unit/set, battery is sold separately.)
Voltage convertor unit used to enable wired operation of the detector
NOTE
These units are designed to detect an intruder and activate an alarm control panel. Being
only a part of a complete system, we cannot accept responsibility for any damages or
other consequences resulting from an intrusion.
These products conform to the EMC Directive 2004/108/EC.
OPTEX TECHNOLOGIES B.V.
(The Netherlands)
www.optex.eu
OPTEX SECURITY SAS (France)
www.optex-security.com
OPTEX SECURITY Sp.z o.o. (Poland)
www.optex.com.pl
- 4 -
Be sure to conduct a walk test at the following three points:
A. In front of the transmitter
B. In front of the receiver
C. At the mid point between the transmitter and receiver
The detector is installed properly when Alarm/Level indicator LED turns
ON in the tests at all the three points.
117 (4.6)
55 (2.2)
34 (1.3)
71 (2.8)
OPTEX PINNACLE INDIA, PVT., LTD. (India)
www.optex.net/in/en/sec
OPTEX KOREA CO.,LTD. (Korea)
www.optexkorea.com
OPTEX (DONGGUAN) CO.,LTD.
SHANGHAI OFFICE (China)
www.optexchina.com
Unit: mm (inch)
Unit: mm (inch)
56 (2.2)
Unit: mm (inch)
20 (0.8)
Unit: mm (inch)
