Optex Smart Line SL-100 TNR Installation Instructions page 2

3
INSTALLATION
3-1 SEPARATING
Remove the battery Remove the main unit
1 2
cover. cover.
1
1 2 Pull Loosen the
Loosen the
battery cover main unit cover
lock screw. lock screw.
3-2 WALL MOUNTING
Using a screwdriver or similar tool, break
1
the knockout position (×2) in the back
box as shown.
Knockout position
POLE (1)
WALL
POLE (2)
Open the screw holes from the
inside of the back box to the
outside.
5 6
Attach the connectors.
< When using D size battery >
1 Open the battery plate in the
2
3
< When using CR123A battery >
1 Open the battery plate in the
Note>>
2
• Avoid placing the cables
in a position where they
can be caught between
3
the main unit and cover.
4
• Do not mix D size lithium batteries with CRH-5 batteries.
• Do not mix batteries that have different levels of power remaining (i.e., new
and used batteries or batteries of different manufacturers). Not observing
the above may result in an explosion, leakage of electrolyte, emission of
toxic gases or other outcomes that may be harmful to people and property.
• Remove all batteries prior to replacing with new ones. If this is not followed,
the low battery indicator LED will not reset and will continue to blink.
3-3 POLE MOUNTING
1
Using the guide below, break the knockout positions (×2) in the back box with a screwdriver.
Knockout position
POLE (1)
WALL
POLE (2)
Knockout position
Instruction
condition
Detector No. 1 Detector No. 2
One detector POLE (1)
Two detectors in
POLE (1)
opposing directions
Remove the connectors.
3
2 Pull
2
Mount the back box to the wall.
Side wall
Distance from
the side wall:
at least 1m
4×20 self tapping
(with rubber washer)
Insert/replace batteries.
direction of the arrow.
Insert the two batteries into their
compartment. Ensure the positive
terminals are facing toward the front.
Close the battery plate.
3.9 VDC D size
Lithium batteries
direction of the arrow.
Set CR123A in the CRH-5 and insert
two CRH-5 into their compartment.
Ensure the positive terminals are
facing toward the front.
Close the battery plate.
CRH-5
Connect the CRH-5 male connectors
3.0 VDC CR123A
to the female connectors of the
battery plate.
Warning
Caution
Disposal method for batteries
Dispose of used batteries in accordance with local
government regulations/low and EU Battery
Directive (2006/66/EU).
Open the screw holes from the inside
of the back box to the outside.
Caution
• If you accidentally open an
unnecessary knockout, be sure
-
to fill the knockout. Not doing so
may result in waterproof failure
POLE (2)
and malfunction of the product.
Remove the main unit from the back box.
4
2
1
1 Turn the optical unit
90 degrees and
loosen the screw.
Using Velcro tape, fix the wireless
3
transmitters in the back box.
For more information on wiring,
see "3-5 WIRING" on page 3.
Pitch: 83.5 mm
For connection
to gang electric Velcro tape
box
Note>>
• When using BCU-4 (option), refer to
BCU-4 manual.
Referring to "4 SETTING" on page 3,
7
3
perform the necessary settings.
1
8
Close the main unit cover.
2
4
• Do not touch the optical unit
when mounting the cover.
Otherwise, the resulting shift
of the optical axis may result
in malfunction of the unit and
require readjustment.
2
Fix the back box on the pole.
Side wall
Distance from the side
wall: at least 1m
M4×20 screw
(with rubber washer)
Pole 43 to 48 mm dia.
(1.69 to 1.89 inch dia.)
- 2 -
Remove the main unit mounting bracket.
5
3
2
Take the main unit out
of the back box.
4
Mount the main unit.
2
Cut the supplied Velcro
tape to an appropriate
length and apply.
3
4
9
Close the battery cover.
1
Close the battery cover.
1 Hook on the upper part
of the back box.
2
3
2
Push the lower part of
2
Tighten the fixing screw for the battery cover.
the main unit cover.
3 Fasten the main unit
cover lock screw.
Caution
• When closing the cover, be careful that
the cables are not caught by the cover.
Detector
No. 2
Pole bracket U-bracket
Detector
No. 1
Caution
• Do not place the main
unit where it is exposed
to direct sunlight. Doing
so may cause damage to
the product.
1 Attach the main unit
mounting bracket to the back
box.
1
2 Route the three connectors
of the back box through the
slits on the upper part of the
main unit.
3 Tighten the main unit fixing
screw and turn the optical unit
90 degrees.
1
Just fit
Caution
3
Perform the wall
mounting procedure of
3 to 9 on page 2.
