Registering Forms (Form Overlay)

Forms for logos, etc. can be registered in the machine for performing overlay printing. This
section describes how to register forms.
·
For information on performing overlay printing, refer to "Overlaying Text or Logos when Printing".
·
Creating Forms
1
Click [Start], and then select [Devices and Printers].
2
Right-click the icon of the machine, and select the required printer driver in [Printer
properties].
3
Select the [Ports] tab, select [FILE:] in [Port], and select [Apply].
4
Create the forms to register to the machine.
5
Print.
6
Enter the file name to save.
Example: C:\temp\form.prn
7
Select the original port in [Port] on the [Ports] tab, and select [OK].
·
Registering Forms to the Machine Using the Configuration Tool
1
Click [Start], and select [General] > [Configuration Tool].
2
Select [Storage Manager] in the [Plug-in] menu.
3
Click [New Project].
