Dimming LEDs
3 B
2 G
1 R
CH
Dimming mode
3 B
2 G
1 R
CH
RGB mode
2. DMX console onnection c
DMX
console
LT-912-OLED
*
If the recoil effect occurs because of longer signal line or bad line quality, please try
to connect 0.25W 90-120Ω terminal resistor at the end of each line.
RGB LEDs
:
LT-912-OLED is equipped with 3 kinds of DMX terminals
for users' selection. The following diagram takes 5-pin XLR
as an example, same connecting method for the rest two:
RJ45 & green terminal (with amplifier function).
S H
P U
S H
P U
3
1
2
3 1
2
DMX signal
LT-912-OLED
3 B
2 G
1 R
CH
Color temperature mode
DMX signal
