ARTHUR HOLM Dynamic3Reverse User Manual

Hdcp compliant aluminium foldable and rotatable motorised monitors
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Guide
Dynamic3Reverse
HDCP compliant aluminium foldable and rotatable
motorised monitors
Technology Serving Design
Danish craftmanship
Mediterranean soul

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dynamic3Reverse and is the answer not in the manual?

Questions and answers

Related Manuals for ARTHUR HOLM Dynamic3Reverse

Summary of Contents for ARTHUR HOLM Dynamic3Reverse

  • Page 1 User Guide Dynamic3Reverse HDCP compliant aluminium foldable and rotatable motorised monitors Technology Serving Design Danish craftmanship Mediterranean soul...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS REGULATIONS AND SECURITY SAFETY INSTRUCTIONS SYSTEM DESCRIPTION CONTROLS OSD MENU ISD MENU INPUT CONNECTORS AHnet PROTOCOL VIDEO SIGNALS AHLink INFORMATION ON DISPOSAL WARRANTY TERMS AND CONDITIONS...
  • Page 3 WELCOME Thank you very much for purchasing an Arthur Holm product. Please, read these installation and operating instructions carefully and keep them in a safe place for future consultations. We remain at your entire disposal if you have any suggestions.
  • Page 4 ABOUT US The Company Arthur Holm has its origins in the Danish furniture designer Jorgen Alex Jensen, who was active during the sixties and the seventies. His design inspiration and his concept of ergonomics have been continued by his family, who is the design force behind Arthur Holm product range. The...

  • Page 5: Regulations And Security

    REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit.
  • Page 6 SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an electrical outlet with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.

  • Page 7: System Description

    SYSTEM DESCRIPTION General Dynamic3Reverse is a unique electrically foldable 18,5" monitor. Its tilt angle can be adjusted to any point, from flush with the desk up to 90°, and it rotates to be folded. The rotation axis is located in the area that...
  • Page 8 SYSTEM DESCRIPTION Available Models MODEL DESCRIPTION HDCP compliant 18,5" Full HD foldable monitor with horizontal and vertical working positions. Can work in a horizontal position levelled with the desk surface or in a vertical position up to 90˚. The monitor can rotate 180˚ and can be folded with the screen facing down.
  • Page 9 SYSTEM DESCRIPTION Box Contents Before the installation of your monitor, please check the contents of the shipping box, it must contain the following items: • Monitor • Power cord • Remote control • Power supply 100-2 40Vac, 50-60Hz. Output 12V •...

  • Page 10: Controls

    CONTROLS Monitor movement controls There are 4 buttons to control the screen’s movements: 1- Position memory 2- Open button control 3- Close button control (screen upwards) 4- Monitor closed (screen downwards) • Open the monitor: Press button 2 once and the monitor will lift up to a position of 70º...
  • Page 11 CONTROLS Remote control POWER Switch ON/OFF the monitor MENU Activates the OSD menu on screen Control up on the OSD menu DOWN Control down on the OSD menu LEFT Control left on the OSD menu RIGHT Control right on the OSD menu Selects the function on the OSD menu.

  • Page 12: Osd Menu

    OSD MENU Accessing the menu system • With the OSD off, push the MENU button to activate the main OSD menu. • Press the UP and DOWN buttons to move from one function to another. Please refer to the following sections below to view a complete list of all the functions available for the monitor.
  • Page 13 OSD MENU Aspect Ratio: Adjusts the image aspect on screen ∙ 4:3 ∙ 16:9 ∙ Zoom1 ∙ Zoom2 ∙ Just scan Noise Reduction: Adjusts the image noise filter ∙ Off ∙ Low ∙ Medium ∙ High ∙ Default Screen: (Only for analogue signals) ∙...
  • Page 14 OSD MENU Option Language: OSD language selection Restore Factory Default: Adjusts the parameters to the initial factory parameters Blending: OSD window transparency ∙ Low ∙ Medium ∙ High ∙ Off OSD Duration: Adjusts the time that the OSD menu window remains on the screen Software Update (USB): Port to use for firmware's upgrade.

  • Page 21: Input Connectors

    INPUT CONNECTORS D.C. Power supply input connector. XLR-4 connector. - 1,2: Ground - 3,4: 12Vdc GPI: Monitor external contact close control. SubD9 female. 1. GPI1 + 2. GPI1 – 3. GPI2 + 4. GPI2 – 5. GPI3 – 6. GPI3 + 7.
  • Page 22 INPUT CONNECTORS Termination: Activate (ON) the termination. Only on the last unit of the RS422 bus. AHnet: RJ45 CAT6 connector for addressable RS422 control. There is a loop through connector to use as signal RS422 output. Up to 30 monitors can be connected on the same RS422 bus.

  • Page 23: Ahnet Protocol

    AHnet PROTOCOL Communications protocol COMMUNICATION RS422 CONNECTION RJ45 WIRING CAT-6 Speed and configuration BAUD RATE 38400 DATA BITS PARITY NONE STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX –...
  • Page 24 AHnet PROTOCOL AHnet protocol Uses 5 bytes communication: BYTE 0 START BYTE BYTE 1 ADDRESS BYTE BYTE 2 COMMAND BYTE BYTE 3 VALUE 1 BYTE 4 VALUE 2 Commands COMMAND DESCRIPTION RESPONSE FA XX 01 01 00 OPEN FB XX 01 01 00 FA XX 01 00 00 MONITOR CLOSED FB XX 01 00 00...
  • Page 25 AHnet PROTOCOL BITE Monitor in horizontal position Monitor in open position Monitor in memorized vertical Monitor closed SCREEN ON SCREEN OFF DVI-A DVI 1 DVI 2 PROTECTION STOP MONITOR OK BITE BUTTON LOCK BUTTON UNLOCK...
  • Page 26 AHnet PROTOCOL Picture Commands COMMAND DESCRIPTION RESPONSE FA XX 15 00 00 ASK FOR BACKLIGHT LEVEL FB XX 15 00 ZZ FA XX 16 00 00 ASK FOR CONTRAST LEVEL FB XX 16 00 ZZ FA XX 17 00 00 ASK FOR BRIGHTNESS LEVEL FB XX 17 00 ZZ Number of the monitor address.

  • Page 27: Video Signals

    VIDEO SIGNALS RESOLUTION Horizontal freq (KHz) Vertical freq (Hz) Scanning type 800x600@60Hz 37.879 60.317 Progressive 800x600@72Hz 48.077 72.188 Progressive 800x600@75Hz 46.875 75.000 Progressive 1024x768@60Hz 48.363 60.005 Progressive 1024x768@70Hz 56.476 70.070 Progressive 1024x768@75Hz 60.023 75.030 Progressive 1280x720@60Hz 44.772 59.855 Progressive 1360x768@60Hz 47.720 59.799 Progressive...

  • Page 28: Ahlink

    AHLink AHlink is used to control and set-up the unit. By default, the AHLink wireless signal is deactivated. To activate it, please press and hold simulatenously the Open (2) and Close (3) buttons on the monitor frame for 5 seconds. You can also activate the AHLink wireless signal by using the Interactive Setup Display (ISD) located below the monitor.
  • Page 29 AHLink your device does appear screen, AHLink signal might no longer be active. The AHLink name always begins with characters “AH” followed by the four last MAC AHLink address. You must select the AH device. After selecting the AH device, the first page will upload on your screen.
  • Page 30 AHLink SERIAL Serial number Firmware version OPEN: Factory screen working position MEM: Memorized screen working position CLOSE: Close monitor CLOSE_FU: Horizontal screen face up working position DISP: Turns the display ON or OFF DVIA, DVI1, DVI2: Input selection BACKL: Backlight adjustments CONTR: Contrast adjustments BRIGHT: Brightness adjustments SAVE VALUES: Memorises the backlight,...

  • Page 31: Information On Disposal

    INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol products and/or accompanying documents means that used electrical electronic products should not be mixed with general household waste. proper treatment, recovery recycling, please take these products designated collection points, where...

  • Page 32: Warranty Terms And Conditions

    WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of two (2) years from the date of purchase, subject to the conditions below. 1. LCD panel, inverler, controller, electrical, electronic boards, engine, mechanical parts, accessories and power supply are warranted against manufacturing defects and workmanship for a period of two (2) years from the date of purchase.
  • Page 33 If you have any doubts concerning the terms of this warranty, please contact: business@albiral.com +34 938 502 376 Copyright © Nov. 2020. All rights reserved Albiral Display Solutions SL. Registered trademarks: Albiral, Arthur Holm...
  • Page 34 Patents P27178ITEP P27178RUPC MU17180ES00 P27178USPC MU17301ES00 P27284DEEP MU17322ES00 P27284EPPC MU17413ES00 P27284ESEP MU17445ES00 P27284GBEP MU17854ES00 P27284RUPC MU17868DEPC P27284USPC MU17868RUPC P27715ESEP P24821DEEP P28089DEEP P24821ESEP P28089ESEP P24821GBEP Fàtima 25, Sant Hipòlit de Voltregà P28089ITEP P24821USPC 08512 Barcelona – Spain P28089USPC P27178DEEP tel: +34 93 850 23 76 / 23 83 P28090EP00 P27178EPDV01 fax: +34 93 850 25 50 / 23 72...

This manual is also suitable for:

Ah18d3rhdga
