ARTHUR HOLM DynamicX2KM User Manual

Hdcp compliant aluminium retractable motorised monitor with a motorised key and mouse
Hide thumbs Also See for DynamicX2KM:

Advertisement

Quick Links

User Guide
DynamicX2KM
AH17DX2KM
AH22DX2KM
HDCP compliant aluminium retractable motorised monitor
with a motorised key and mouse
Technology Serving Desing
Danish craftmanship
Mediterranean soul

Advertisement

Table of Contents
loading

Summary of Contents for ARTHUR HOLM DynamicX2KM

  • Page 1 User Guide DynamicX2KM AH17DX2KM AH22DX2KM HDCP compliant aluminium retractable motorised monitor with a motorised key and mouse Technology Serving Desing Danish craftmanship Mediterranean soul...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS EC REGULATIONS AND SECURITY SAFETY INSTRUCTIONS SYSTEM DESCRIPTION CONTROLS OSD MENU INPUT CONNECTORS AHLINK INPUT SIGNALS AHNET INFORMATION ON DISPOSAL WARRANTY TERMS AND CONDITIONS...
  • Page 4 WELCOME Thank you for purchasing an ARTHUR HOLM product. Our product range has been designed for a seamless integration and for a maximum reliability. Please, read this installation and operating instructions carefully and keep them in a safe place for future reference.
  • Page 5 ABOUT US The Company Arthur Holm has its origins in the Danish furniture designer Jorgen Alex Jensen, who was active during the sixties and the seventies. His design inspiration and his concept of ergonomics have been continued by his family, who is the design force behind Arthur Holm product range. The...
  • Page 6: Ec Regulations And Security

    EC REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit.
  • Page 7 SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an elec- trical outlet with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.
  • Page 8: System Description

    SYSTEM DESCRIPTION Applications Dynamicx2 monitor combined with an automated keyboard and mouse, creating a motorised automation system that lifts the keyboard and mouse at the same time the monitor is being raised. This combination offers the best possible quality Full HD screen with an elegant keyboard and mouse storage that converts into a work station by the touch of a button.
  • Page 9 CONTROLS Remote IR control POWER Switch ON/OFF the monitor MENU Activates the OSD menu on screen Cursor control up on the OSD menu DOWN Cursor control down on the OSD menu LEFT Cursor control left on the OSD menu RIGHT Cursor control right on the OSD menu Selects the function on the OSD menu.
  • Page 10: Controls

    CONTROLS IR sensor The IR sensor is located on the lower right side of the screen. Monitor movement controls On the upper cover plate, there is one button to control the UP and DOWN monitor movements. OSD MENU Accessing the menu system •...
  • Page 11 OSD MENU Screen ARC: Adjusts the image aspect on screen ∙ 16:9: Shows the image on screen with 16:9 aspect ∙ 4:3: Shows the image on screen with 4:3 aspect ∙ Just scan Noise Reduction: Adjusts the image noise filter ∙...
  • Page 12: Input Connectors

    OSD MENU Setup Language: OSD language selection Restore Factory Default: Adjusts the parameters to the initial factory parameters Blending: OSD window transparency ∙ Low ∙ Medium ∙ High ∙ Off OSD Duration: Adjusts the time that the OSD menu window remains on screen Software Update: Used for firmware upgrade mirror Mirror:...
  • Page 13 INPUT CONNECTORS DVI 1/DVI A: DVI-I input signal. Connect a DVI (digital) input signal and select DVI 1 on the OSD monitor menu. Use a DVI to VGA adapter to connect an ARGB (analogue) input signal and select DVI-A on the OSD monitor menu DVI 2: DVI-D input signal.
  • Page 14: Ahlink

    AHLINK AHlink is used to control and set-up the unit. By default, the AHlink signal on the unit is deactivated. To activate the AHlink signal, press for 5 seconds the external Up and Down screen buttons located on the cover plate, or press for 5 seconds the UP and Down contact close on the GPI connector.
  • Page 15 AHLINK If the device does not appear on the window, the AHlink signal is not active. The AHlink name always begins with AH characters and the fourth last MAC AHlink address. Select the device to control and set-up the unit. When selecting the device, the first page will upload on the mobile phone.
  • Page 16 AHLINK SERIAL Serial number of the unit Firmware version Controls the Up and Down screen movements DISP: Turns the display ON or OFF DVIA, DVI1, DVI2: Input source selection BACKL: Configuration of the display's backlight CONTR: Configuration of the display's contrast BRIGHT: Configuration of the display's brightness...
  • Page 17: Input Signals

    INPUT SIGNALS RESOLUTION Horizontal freq (KHz) Vertical freq (Hz) Scanning type 800x600@60Hz 37.879 60.317 Progressive 800x600@72Hz 48.077 72.188 Progressive 800x600@75Hz 46.875 75.000 Progressive 1024x768@60Hz 48.363 60.005 Progressive 1024x768@70Hz 56.476 70.070 Progressive 1024x768@75Hz 60.023 75.030 Progressive 1280x720@60Hz 44.697 59.915 Progressive 1280x768@60Hz 47.396 59.995 Progressive...
  • Page 18 AHNET PROTOCOL Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX RJ-45 7. NC 8. NC Connection PINS 1 & 2 The units respond PINS 3 & 6 The units receive instructions Protocol to control the unit by addressable RS422 bus.
  • Page 19 AHNET PROTOCOL Commands COMMAND DESCRIPTION RESPONSE GO UP FB XX 08 01 00 FA XX 01 01 00 GO DOWN FB XX 08 00 00 FA XX 01 00 00 BUTTON LOCK FB XX 08 05 00 FA XX 04 01 00 BUTTON UNLOCK FB XX 08 04 00 FA XX 04 00 00 FA XX 14 00 00 INQUIRY CONTROL BYTE FB XX 14 CB1 CB2 FA XX 02 01 00...
  • Page 20 AHNET PROTOCOL BITE CLOSED OPENED To send an order to all the devices, you must use the address: F6 Hex. (Byte1) In this case, the units do not send a reply. Use shielded (FTP) RJ45 cables for RS422 BUS. Picture commands: COMMAND DESCRIPTION RESPONSE...
  • Page 21: Information On Disposal

    INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to the designated collection points, where they will be accepted on a free of charge basis.
  • Page 22: Warranty Terms And Conditions

    WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of five (5) years from the date of purchase, subject to the conditions below. 1. Mechanical parts: The engine and the product’s mechanical parts are warranted against manufacturing defects and workmanship for a period of five (5) years from the date of purchase.
  • Page 23 If you have any doubts concerning the terms of this warranty, please contact: business@albiral.com +34 938 502 376 Copyright © Dec. 2020. All rights reserved Albiral Display Solutions SL. Registered trademarks: Albiral, Arthur Holm, Pixtron Broadcast...
  • Page 26 Patents P27178ITEP P27178RUPC MU17180ES00 P27178USPC MU17301ES00 P27284DEEP MU17322ES00 P27284EPPC MU17413ES00 P27284ESEP MU17445ES00 P27284GBEP MU17854ES00 P27284RUPC MU17868DEPC P27284USPC MU17868RUPC P27715ESEP P24821DEEP P28089DEEP P24821ESEP P28089ESEP P24821GBEP Fàtima 25, Sant Hipòlit de Voltregà P28089ITEP P24821USPC 08512 Barcelona – Spain P28089USPC P27178DEEP tel: +34 93 850 23 76 / 23 83 P28090EP00 P27178EPDV01 fax: +34 93 850 25 50 / 23 72...
