TABLE OF CONTENTS REGULATIONS AND SECURITY SAFETY INSTRUCTIONS SYSTEM DESCRIPTION INSTALLATION INSTRUCTIONS DYNAMICSHARE DYNAMICSHARE INSTALLATION CONTROLS OSD MENU ISD MENU INPUT CONNECTORS AHnet PROTOCOL VIDEO SIGNALS AHLink INFORMATION ON DISPOSAL WARRANTY TERMS AND CONDITIONS...
Page 3
WELCOME Thank you very much for purchasing an Arthur Holm product. Please, read these installation and operating instructions carefully and keep them in a safe place for future consultations. We remain at your entire disposal if you have any suggestions.
Page 4
ABOUT US The Company Arthur Holm has its origins in the Danish furniture designer Jorgen Alex Jensen, who was active during the sixties and the seventies. His design inspiration and his concept of ergonomics have been continued by his family, who is the design force behind Arthur Holm product range. The...
EC REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit.
Page 6
SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an electrical out- let with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.
The use of the Arthur Holm’s ERT will enable the address configuration of all the monitors installed in a table by simply pressing a button. The AHlink Android and iOS app allows getting the monitor’s serial number without removing the unit from the table and allows access to the setup and control menus.
Page 8
SYSTEM DESCRIPTION Available Models MODEL DESCRIPTION HDCP compliant vertically retractable aluminium 17,3" Full HD monitor with 20 degrees of adjustable inclination. The monitor allows its installation flush with the desk when the monitor is in recessed position and a motorised retractable HDMI cable rises as an extension AH17DB2Share of the monitor.
Page 10
SYSTEM DESCRIPTION Box Contents Before the installation of your retractable monitor, please check the contents of the shipping box, it must contain the following items: • Monitor • Power cord • Remote control (1 per 5 monitors) • Power supply 100-2 40Vac, 50-60Hz. Output 12V •...
Cutting, drilling, soldering, adding electrical and mechanical components can cause danger and should be avoided by all means. Not complying with these directions will result in a loss of the Arthur Holm warranty. Albiral Display Solutions S.L. shall not be held liable for any loss...
Page 12
INSTALLATION INSTRUCTIONS Mounting table brackets Mount the table brackets below the table using the holes indicated IN the corresponding Pattern Hole drawing. The screws (x6) are not supplied. The weight of the monitor is up to 25Kg / 55.16 Lbs. PAY ATTENTION THAT THE BRACKETS ARE MOUNTED IN THEIR CORRESPONING SIDE.
Page 13
INSTALLATION INSTRUCTIONS Mounting the monitor brackets Mount the monitor brackets in their corresponding side using the supplied screws. Mount the vertical adjustment screws (2+2) on to the monitor bracket so that the tip of the screw is flushed with the upper side of the monitor bracket.
Page 14
INSTALLATION INSTRUCTIONS Checking assembly View from below the table: View from above the monitor: Dimensions A and B in table brackets and in monitor brackets must be the same (+-1mm). If adjustment is necessary loosen 3+3 Table bracket screws, keeping always symmetry regarding to the monitor hole in the table.
Page 15
INSTALLATION INSTRUCTIONS Hanging the monitor Mount 2+2 nuts on to both table brackets as indicated in the drawing. Hang the monitor above nuts.
Page 16
INSTALLATION INSTRUCTIONS Centring the monitor Tighten each nut gradually until the monitor surface is levelled with the table surface. Air gap around the monitor have to be 2mm [0,08]. Otherwise the monitor could come in contact with the table while opening and be damaged.
Page 17
INSTALLATION INSTRUCTIONS Fine centring of the monitor In case fine centring of the monitor is necessary:...
GENERAL DYNAMICSHARE INFORMATION DynamicShare is an equivalent to multiple HDMI selectors connected to multiple cascade HDMI distribution amplifiers in a daisy chain topology, allowing the user to display local sources privately, without affecting the other users in the loop and allowing to share a local signal to the rest of the monitors.
Page 19
GENERAL DYNAMICSHARE INFORMATION Installation Connect a HDMI cable from HDMI LOOP out connector to HDMI LOOP in of the next unit. Create a HDMI loop connecting HDMI cables from the LOOP out and the LOOP in of the next unit. Maximum length of the HDMI cable: 2 meters.
Page 20
GENERAL DYNAMICSHARE INFORMATION When installing the system for the first time, it is necessary to identify the MASTER unit. The MASTER unit is identified with a label. Connect the MASTER unit to your network to access to the DynamicShare configuration. MASTER factory IP is 192.168.0.125. Using a PC in the same IP network that the MASTER unit (192.168.0.125), type the IP address on a web browser, such as Explorer, Firefox, etc.
Page 21
GENERAL DYNAMICSHARE INFORMATION If you access to a CLIENT unit, this window will appear: You can “Demote To Normal client” or “Promote To Master” one unit through the web configuration page. Make sure that just only one MASTER is connected in one loop. If there are more than one MASTER connected in the same HDMI loop, the system will not work properly.
GENERAL DYNAMICSHARE INFORMATION To rebuild the Loop is only necessary during the first installation, or if you remove or introduce a client in to the loop Share system in the future. When the MASTER unit detects all the units installed in the Share system, the Share system is ready to work.
Page 23
GENERAL DYNAMICSHARE INFORMATION Start up Every time that the share system starts up, the MASTER unit will check the health of the HDMI loop. It should take around 3 minutes to finish this operation. During this operation, the MASTER unit checks the loop and the units installed in the Share system.
Page 24
GENERAL DYNAMICSHARE INFORMATION Using DynamicShare To activate the PRIVATE mode, press the button for 5 seconds (the green LED will be on). In private mode, the monitor will always display the local input, even if another monitor activates the share function. VIEW push button: This button selects the input signal to be shown on the screen (local HDMI input or loop share input).
CONTROLS IR sensor The IR sensor is located on the lower side of the screen. Monitor movement controls 1. Open / Close / Tilt button: Up and Down control movements button. When the monitor is up, hold down this button to make the monitor tilt up and down in a cycle.
Page 26
CONTROLS Remote control POWER Switch ON/OFF the monitor MENU Activates the OSD menu on screen Control up on the OSD menu DOWN Control down on the OSD menu LEFT Control left on the OSD menu RIGHT Control right on the OSD menu Selects the function on the OSD menu.
OSD MENU Accessing the menu system • With the OSD off, push the MENU button to activate the main OSD menu. • Press the UP and DOWN buttons to move from one function to another. Please refer to the following sections below to view a complete list of all the functions available for the monitor.
Page 28
OSD MENU Noise Reduction: Adjusts the image noise filter ∙ Off ∙ Low ∙ Medium ∙ High ∙ Default Screen: (Only for analogue signals) ∙ Auto Adjust ∙ Horizontal Position ∙ Vertical Position ∙ Size ∙ Phase Backlight: Adjusts the backlight screen's level Colour Range: Adjusts the colour range ∙...
Page 29
OSD MENU Option Language: OSD language selection Restore Factory Default: Adjusts the parameters to the initial factory parameters Blending: OSD window transparency ∙ Low ∙ Medium ∙ High ∙ Off OSD Duration: Adjusts the time that the OSD menu window remains on the screen Software Update (USB): Port to use for firmware's upgrade.
Page 37
INPUT CONNECTORS HDMI LOOP OUT: Connect a HDMI cable to the next HDMI LOOP IN monitor in order to create a daisy chain loop installation. HDMI LOOP IN: Connect a HDMI cable from the previous HDMI LOOP OUT monitor, in order create a daisy chain loop installation.
AHnet PROTOCOL Communications protocol COMMUNICATION RS422 CONNECTION RJ45 WIRING CAT-6 Speed and configuration BAUD RATE 38400 DATA BITS PARITY NONE STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX –...
Page 39
AHnet PROTOCOL AHnet protocol Uses 5 bytes communication: BYTE 0 START BYTE BYTE 1 ADDRESS BYTE BYTE 2 COMMAND BYTE BYTE 3 VALUE 1 BYTE 4 VALUE 2 Commands COMMAND DESCRIPTION RESPONSE FA XX 01 01 00 SCREEN UP FB XX 01 01 00 FA XX 01 00 00 SCREEN DOWN FB XX 01 00 00...
Page 40
AHnet PROTOCOL BITE SCREEN DOWN SCREEN UP SCREEN ON SCREEN OFF PROTECTION STOP MONITOR OK BITE BUTTON LOCK BUTTON UNLOCK...
Page 41
AHnet PROTOCOL Picture Commands COMMAND DESCRIPTION RESPONSE FA XX 15 00 00 ASK FOR BACKLIGHT LEVEL FB XX 15 00 ZZ FA XX 16 00 00 ASK FOR CONTRAST LEVEL FB XX 16 00 ZZ FA XX 17 00 00 ASK FOR BRIGHTNESS LEVEL FB XX 17 00 ZZ Number of the monitor address.
Page 42
AHnet PROTOCOL Communications protocol Speed and configuration COMMUNICATION RS422 BAUD RATE 38400 CONNECTION RJ45 DATA BITS WIRING CAT-6 PARITY NONE STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX –...
Page 43
AHnet PROTOCOL AHnet protocol Uses 5 bytes communication: BYTE 0 START BYTE BYTE 1 ADDRESS BYTE BYTE 2 COMMAND BYTE BYTE 3 VALUE 1 BYTE 4 VALUE 2 AHnet commands COMMAND DESCRIPTION RESPONSE FA XX 05 00 00 VIEW LOOP FB XX 05 00 00 FA XX 05 01 00 VIEW HDMI1...
Page 44
AHnet PROTOCOL Web API commands Another way to externally control the SHARE system is to use WEB API commands. Use the MASTER RJ45 Ethernet connector to send WEB API commands by network to the SHARE system. Use the following structure to send WEB API commands to the system: IP factory MASTER device 192.168.0.125 Command structure:...
AHLink AHlink is used to control and set-up the unit. By default, the AHlink wireless signal is deactivated. To activate it, please press and hold simultaneously the Open (1) (located on monitor top) and Close (2) (located on glass) for 5 seconds. You can also activate the AHlink wireless signal by suing the Interactive Setup Display (ISD) located below the monitor.
Page 47
AHLink If your AH device does not appear on the screen, the AHLink signal might no longer be active. The AHLink name always begins with the characters “AH” followed by the four last MAC AHLink address. You must select the AH device. After selecting the AH device, the first page will upload on your screen.
Page 48
AHLink SERIAL Serial number of the unit Firmware version Controls the Up and Down monitor movements DISP: Turns the display ON or OFF DVIA, DVI1, DVI2: Input source selection BACKL: Backlight adjustments CONTR: Contrast adjustments BRIGHT: Brightness adjustments SAVE VALUES: Memorises the backlight, contrast and brightness values AHLINK OFF: Turns off the AHlink signal COMMAND: Information of the last AHnet...
INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to the designated collection points, where they will be accepted on a free of charge basis.
WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of five (5) years from the date of purchase, subject to the conditions below. Mechanical parts: The engine and the product’s mechanical parts are warranted against manufacturing defects and workmanship for a period of five (5) years from the date of purchase.
