  • Page 1 User Guide Dynamic3Talk HDCP compliant aluminium foldable and rotatable monitors with integrated independent microphone lift system Technology Serving Design Danish craftmanship Mediterranean soul...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS REGULATIONS AND SECURITY SAFETY INSTRUCTIONS SYSTEM DESCRIPTION BEFORE INSTALLATION BEFORE SHIPPING INSTALLATION INSTRUCTIONS CONTROLS OSD MENU ISD MENU INPUT CONNECTORS MONITOR AHnet PROTOCOL DynamicTalk AHnet PROTOCOL VIDEO SIGNALS AHLink INFORMATION ON DISPOSAL WARRANTY TERMS AND CONDITIONS...
  • Page 3 WELCOME Thank you very much for purchasing an Arthur Holm product. Please, read these installation and operating instructions carefully and keep them in a safe place for future consultations. We remain at your entire disposal if you have any suggestions.
  • Page 4 ABOUT US The Company Arthur Holm has its origins in the Danish furniture designer Jorgen Alex Jensen, who was active during the sixties and the seventies. His design inspiration and his concept of ergonomics have been continued by his family, who is the design force behind Arthur Holm product range. The...
  • Page 5: Regulations And Security

    REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit.
  • Page 6 SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an electrical outlet with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.
  • Page 7: System Description

    SYSTEM DESCRIPTION General Arthur Holm Dynamic3Talk is a motorised product range that provides different working positions includes independent lift “gooseneck” microphones. The aluminium monitor housing rises leans, has an additional 180° rotation movement, and retracts inside the work surface in 2 different positions: with the monitor oriented up or down.
  • Page 8 SYSTEM DESCRIPTION Available Models MODEL DESCRIPTION HDCP compliant 17,3" Full HD foldable monitor with horizontal and vertical working positions including an independent lift for “gooseneck” type microphones. Can work in a horizontal position levelled with the desk surface or in a vertical position with 20˚ of variable inclination. The monitor can rotate 180˚...
  • Page 9 SYSTEM DESCRIPTION Available Models MODEL DESCRIPTION HDCP compliant 18,5" Full HD foldable monitor with horizontal and vertical working positions including an independent lift for “gooseneck” type microphones. Can work in a horizontal position levelled with the desk surface or in a vertical position with 20˚ of variable inclination. The monitor can rotate 180˚...
  • Page 10 SYSTEM DESCRIPTION Options AH17D3RHDGATalk AH17D3HDGATalk AH19D3RHDGATalk AH19D3HDGATalk CL (Min.5 units) CL (Min.5 units) CL (Min.5 units) CL (Min.5 units) Laser engraved logo Laser engraved logo Laser engraved logo Laser engraved logo TS170HDG TS170HDG TS190HDG TS190HDG Projected capacitive Projected capacitive Projected capacitive Projected capacitive multitouch screen.
  • Page 11 SYSTEM DESCRIPTION Box Contents Before the installation of your monitor, please check the contents of the shipping box, it must contain the following items: • Monitor • Power cord • Remote control • Power supply 100-2 40Vac, 50-60Hz. Output 12V •...
  • Page 12: Before Installation

    BEFORE MONITOR INSTALLATION Make sure to follow these steps before installing the device: Remove the 2 lateral transport plastic screws M8x30. Remove the 2 frontal transport plastic screws M8x30. Dynamic3 is ready to be installed.
  • Page 13: Before Shipping

    BEFORE MONITOR SHIPPING Follow the next steps to pack the device for a safe shipment: For a safety shipment all screws must be of plastic. Otherwise Albiral Display Solutions S.L. is not responsible for damage caused during transport. Close the monitor carefully by hand to the position shown in the next figure: Hold the monitor with the hand between the frame and the monitor housing.
  • Page 14: Installation Instructions

    Not complying with these direction will result in a lost of the Arthur Holm warranty. Albiral Display Solution S.L. shall not be held liable for any loss or injury incurred as a result of modifications made to goods by anyone other than the supplier or the supplier's authorised representative without the supplier's written permission.
  • Page 15 DynamicTalk INSTALLATION INSTRUCTIONS Preparing the assemble Assembling DynamicTalk pt.1...
  • Page 16 DynamicTalk INSTALLATION INSTRUCTIONS Assembling DynamicTalk pt.2 Assembling DynamicTalk pt.3...
  • Page 17 DynamicTalk INSTALLATION INSTRUCTIONS Assembling DynamicTalk (STANDARD & BOSCH) Assembling DynamicTalk (DIS)
  • Page 18: Controls

    CONTROLS Monitor movement controls Three buttons are placed on the upper cover plate: 1. Open 2. Rotate 3. Close Raising the monitor: To raise and tilt the monitor, press the open button (1) on the right hand side of the cover plate. To adjust the angle, press and hold this button (1) while the monitor is open;...
  • Page 19 CONTROLS Remote control POWER Switch ON/OFF the monitor MENU Activates the OSD menu on screen Control up on the OSD menu DOWN Control down on the OSD menu LEFT Control left on the OSD menu RIGHT Control right on the OSD menu Selects the function on the OSD menu.
  • Page 20: Osd Menu

    OSD MENU Accessing the menu system • With the OSD off, push the MENU button to activate the main OSD menu. • Press the UP and DOWN buttons to move from one function to another. Please refer to the following sections below to view a complete list of all the functions available for the monitor.
  • Page 21 OSD MENU Aspect Ratio: Adjusts the image aspect on screen ∙ 4:3 ∙ 16:9 ∙ Zoom1 ∙ Zoom2 ∙ Just scan Noise Reduction: Adjusts the image noise filter ∙ Off ∙ Low ∙ Medium ∙ High ∙ Default Screen: (Only for analogue signals) ∙...
  • Page 22 OSD MENU Option Language: OSD language selection Restore Factory Default: Adjusts the parameters to the initial factory parameters Blending: OSD window transparency ∙ Low ∙ Medium ∙ High ∙ Off OSD Duration: Adjusts the time that the OSD menu window remains on the screen Software Update (USB): Port to use for firmware's upgrade.
  • Page 23: Isd Menu

    ISD MENU The Interactive Setup Display is an LCD screen located at the monitor casing inside the desk that allows the setup and provides useful diagnose and historical data of the device. - To start using it - ∙ WELCOME DISPLAY & DATA : 1) Bootloader Version The display will show a Bootloader Version message (example: Bootl.
  • Page 24 ISD MENU 2) FirmWare Data that refers to the firmware version (FW) of the equipment (example: FW Ver = 1.32). If you wish to update the FW version, please contact us. 3) Serial Number Serial number of the device (example: serial number of the device = 02658748). The serial number is stored inside each device.
  • Page 25 ISD MENU ∙ MENUS GENERAL INFORMATION 1) AHnet - Adress The address must be set from 1 to 60. 2) VIDEO INPUT SELECTION The device provides the following inputs: DVI1 = DVI-I (DVI-A and DVI1-D) DVI2= DVI-D (DVI-2D) This menu allows the selection of 1 of these 3 inputs. 3) MONITOR BRIGHTNESS Brightness level (0 –...
  • Page 26 ISD MENU 5) MONITOR BACKLIGHT Backlight level (0 – 100). 6) POSITION It is a diagnostic option that informs about the position of the device. 7) SENSORS INFORMATION It is a diagnostic option that informs about the internal state of the sensors. 8) AHnet - INFORMATION This menu is useful for programing and diagnose.
  • Page 27 ISD MENU 9) UNIT OPENS It is a diagnostic option that provides historical data. It is very useful to analyze how the device has been used during its lifecycle and it provides information about how many movements the device has done. 10) UNIT STOPS It is a diagnostic option that provides historical data.
  • Page 28 ISD MENU 13) AUTO ADJUST Auto Mechanical Movement Calibration (AH-AMMC). Protocol activation: the device will make a consecutive movements series that must not be interrupted. The system will calibrate the speed and protection thresholds. 14) AHLink Activates AHlink. FIRMWARE UPDATE To update the FW version.
  • Page 29: Input Connectors

    INPUT CONNECTORS 12V D.C. Power supply input connector. XLR-4 connector. - 1,2: Ground - 3,4: 12Vdc GPI: Monitor external contact close control. SubD9 female. 1. GPI1 + 2. GPI1 – 3. GPI2 + 4. GPI2 – 5. GPI3 – 6. GPI3 + 7.
  • Page 30 INPUT CONNECTORS MICROPHONE INPUT CONNECTORS AHnet: RJ45 CAT5 connector for addressable RS422 control. There is a loop through connector to use as signal RS422 output. You can connect up to 30 devices on the same RS422 bus. AHnet ADDRESS: Using the AHnet protocol, this is the number of the device into the RS422 addressable bus.
  • Page 31 INPUT CONNECTORS GPI/GPO external contact close connector: 1. GND. 2. Command microphone UP connecting to GND. Connecting to GND more than 2 seconds, activates the AHlink signal (5 beeps sounds when the AHlink signal is activated) 3. Command microphone DOWN connecting to GND. - Use a pulse signal to RISE and LOWER the microphone 4.
  • Page 32: Monitor Ahnet Protocol

    MONITOR AHnet PROTOCOL Communications protocol COMMUNICATION RS422 CONNECTION RJ45 WIRING CAT-6 Speed and configuration BAUD RATE 38400 DATA BITS PARITY NONE STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX –...
  • Page 33 MONITOR AHnet PROTOCOL AHnet protocol Uses 5 bytes communication: BYTE 0 START BYTE BYTE 1 ADDRESS BYTE BYTE 2 COMMAND BYTE BYTE 3 VALUE 1 BYTE 4 VALUE 2 Commands COMMAND DESCRIPTION RESPONSE FA XX 01 01 00 OPEN FB XX 01 01 00 FA XX 01 00 00 CLOSE SCREEN DOWNWARDS FB XX 01 00 00...
  • Page 34 MONITOR AHnet PROTOCOL BITE CLOSED OPENED CLOSED SCREEN FACE UP MONITOR 90˚ POSITION SCREEN ON SCREEN OFF DVI-A DVI 1 DVI 2 PROTECTION STOP MONITOR OK BITE BUTTON LOCK BUTTON UNLOCK...
  • Page 35 MONITOR AHnet PROTOCOL Picture Commands COMMAND DESCRIPTION RESPONSE FA XX 15 00 00 ASK FOR BACKLIGHT LEVEL FB XX 15 00 ZZ FA XX 16 00 00 ASK FOR CONTRAST LEVEL FB XX 16 00 ZZ FA XX 17 00 00 ASK FOR BRIGHTNESS LEVEL FB XX 17 00 ZZ Number of the monitor address.
  • Page 36: Dynamictalk Ahnet Protocol

    DYNAMICTALK AHnet PROTOCOL Communications protocol Speed and configuration BAUD RATE 38400 COMMUNICATION RS422 DATA BITS CONNECTION RJ45 PARITY NONE WIRING CAT-5 STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX RJ-45 7.
  • Page 37 DYNAMICTALK AHnet PROTOCOL Commands COMMAND DESCRIPTION RESPONSE FA XX 01 01 00 FB XX 01 01 00 GO UP FA XX 01 00 00 GO DOWN FB XX 01 00 00 FA XX 02 01 00 FB XX 02 01 00 MUTE ON (Only in PA mode) FA XX 02 00 00 FB XX 02 00 00...
  • Page 38: Video Signals

    VIDEO SIGNALS AH17D3 HDGA / AH19D3 HDGA / AH17D3 RHDGA/ AH19D3 RHDGA / RESOLUTION Horizontal freq (KHz) Vertical freq (Hz) Scanning type 800x600@60Hz 37.879 60.317 Progressive 800x600@72Hz 48.077 72.188 Progressive 800x600@75Hz 46.875 75.000 Progressive 1024x768@60Hz 48.363 60.005 Progressive 1024x768@70Hz 56.476 70.070 Progressive 1024x768@75Hz...
  • Page 39: Ahlink

    AHLink AHlink is used to control and set-up the unit. By default, the AHLink wireless signal is deactivated. To activate it for the D3 or D3R, please press and hold simulatenously the Open (1) and Close (3) buttons on the cover plate for 5 seconds. You can also activate the AHLink wireless signal by using the Interactive Setup Display (ISD) located below the monitor.
  • Page 40 AHLink your device does appear screen, AHLink signal might no longer be active. The AHLink name always begins with characters “AH” followed by the four last MAC AHLink address. You must select the AH device. After selecting the AH device, the first page will upload on your screen.
  • Page 41 AHLink SERIAL Serial number Firmware version Open and Close screen movement’s control DISP: Turns the display ON or OFF DVIA, DVI1, DVI2: Input selection BACKL: Backlight adjustments CONTR: Contrast adjustments BRIGHT: Brightness adjustments SAVE VALUES: Memorises the backlight, contrast and brightness values AHLINK OFF: Turns off the AHlink signal COMMAND: Information of the last AHnet command received from RS422 port...
  • Page 42 AHLink SERIAL Serial number Firmware version Open and Close screen movement’s control and close screen face up (rotation) DISP: Turns the display ON or OFF DVIA, DVI1, DVI2: Input selection BACKL: Backlight adjustments CONTR: Contrast adjustments BRIGHT: Brightness adjustments SAVE VALUES: Save settings...
  • Page 43 AHLink DynamicTalk FIRST LINE, SHOWS THE MODEL NAME OF THE DEVICE SERIAL Serial number of the unit Firmware version Controls Down screen movements Controls the microphone on PA mode BEEP: Sounds Beep while pressing this button. Use this function to identify the unit connected BT OFF: Switch off the AHlink signal on the device.
  • Page 44 DYNAMICTALK AHLink DynamicTalk CONFIGURATION AHNET ADDRESS: AH address settings MIC LENGHT: Microphone length configuration in steps. One step is aprox. one cm TERM: Configuration of the RS422 termination. Activate the RS422 termination only in the last unit of the RS422 Bus MODE: Dynamic Talk working mode.
  • Page 45: Information On Disposal

    INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol products and/or accompanying documents means that used electrical electronic products should not be mixed with general household waste. proper treatment, recovery recycling, please take these products designated collection points, where...
  • Page 46: Warranty Terms And Conditions

    WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of two (2) years from the date of purchase, subject to the conditions below. 1. LCD panel, inverler, controller, electrical, electronic boards, engine, mechanical parts, accessories and power supply are warranted against manufacturing defects and workmanship for a period of two (2) years from the date of purchase.
  • Page 47 If you have any doubts concerning the terms of this warranty, please contact: business@albiral.com +34 938 502 376 Copyright © Nov. 2020. All rights reserved Albiral Display Solutions SL. Registered trademarks: Albiral, Arthur Holm...
  • Page 48 Patents P27178ITEP P27178RUPC MU17180ES00 P27178USPC MU17301ES00 P27284DEEP MU17322ES00 P27284EPPC MU17413ES00 P27284ESEP MU17445ES00 P27284GBEP MU17854ES00 P27284RUPC MU17868DEPC P27284USPC MU17868RUPC P27715ESEP P24821DEEP P28089DEEP P24821ESEP P28089ESEP P24821GBEP Fàtima 25, Sant Hipòlit de Voltregà P28089ITEP P24821USPC 08512 Barcelona – Spain P28089USPC P27178DEEP tel: +34 93 850 23 76 / 23 83 P28090EP00 P27178EPDV01 fax: +34 93 850 25 50 / 23 72...
