- Page 1 Mounting Guide Pg. 2-8 Veneer Guide (Optional) Pg.9-15 Mounting Instructions DB2 & DB1Twin AHDB2DOC01...
- Page 2 Not complying with these direction will result in a lost of the Arthur Holm warranty. Albiral Display Solution S.L. shall not be held liable for any loss or injury incurred as a result of modifications made to goods by anyone other than the supplier or the supplier's authorised representative without the supplier's written permission.
- Page 3 Front Side Front Side View from below the table View from below the table Table Bracket Table Bracket “A” “B” Mount the table brackets below the table using the holes indicated on the corresponding Pattern Hole drawing. The screws (x6) are not supplied; The weight of the monitor is up to 25Kg. PAY ATTENTION THAT THE BRACKETS ARE MOUNTED IN THEIR CORRESPONING SIDE Mounting table brackets...
- Page 4 Right Monitor bracket “1” (X4 Screw M6x20) Left Monitor bracket “2” Front Side (X4 washer) (x4) Vertical Adjustment Screws Mount the monitor brackets on their corresponding side using the supplied screws Mount the vertical adjustment screws (2+2) on to the monitor bracket so that the tip of the screw is flushed with the upper side of the monitor bracket.
- Page 5 Front Side View from below the table View from above the monitor Front Side Dimensions A and B in table brackets and in monitor brackets must be the same (+ 1mm). If adjustment is necessary loosen 3+3 Table bracket screws, keeping always symmetry regarding to the monitor hole in the table.
- Page 6 Mount 2+2 nuts on to both table brackets as indicated on the drawing. Hang the monitor above nuts Front Side Hanging the monitor...
- Page 7 Tighten each nut gradually until the monitor surface is levelled with the table surface. Front Side Air gap around the monitor have to be 2mm [0,08]. Otherwise the View from above the monitor could come in contact table with the table while opening and be damaged Front Side Centring the monitor...
- Page 8 In case fine centering of the monitor is necessary For adjusting the monitor to the left or right loosen the table screws half a turn and centre the Front Side monitor. When the monitor is centred tighten the six screws. For adjusting the monitor closer or View from below the table further away from the table edge...
- Page 9 INTRODUCTION The DB2 and DB1Twin monitors are available in a special version that is prepared to be mounted from below the table with a Veneer finishing on the top of the monitor to match the table. The Veneer is not supplied. The Veneer option (V1, V2, V3) are available under request.
- Page 10 OPTION 1 - Double-side tape or glue used can’t be thicker than 0,2-0,25mm [0.008-0.01] 1. Check if the Veneer fits perfectly with the monitor. To join both parts correctly it is important that the two surfaces are touching each other in the whole length. (To make easier the adjustment the hight of the touch button can be barely adjusted.) 2.
- Page 11 OPTION 1 VENEER CUT-OUT DB2 Veneer cut-out AH10DB2 AH17DB2 AH22DB2 AH24DB2 "A" 258[10.15] 424[16.7] 518[20.39] 559,2[22] "B" 17[0.67] 20[0.78] 20[0.78] 20[0.78] "C" 8[0.31] 7,5[0.29] 7,5[0.29] 10[0.39] DB1Twin Veneer cut-out Veneer Guide (Optional)
- Page 12 OPTION 2 - Distance Plate material can’t be conductor. Wood or DM are advisable. - Veneer material can’t be conductor. 1. Check if the Distance Plate fits perfectly with the monitor. The copper cylinder can’t project outwards from the Distance Plate surface. (To make easier the adjustment the hight of the copper cylinder can be barely adjusted.) 4.
- Page 13 OPTION 2 VENEER CUT-OUT DB2 Veneer cut-out DB2 Distance plate cut-out AH10DB2 AH17DB2 AH22DB2 AH24DB2 "A" 258[10.15] 424[16.7] 518[20.39] 559,2[22] "B" 17[0.67] 20[0.78] 20[0.78] 20[0.78] "C" 8[0.31] 7,5[0.29] 7,5[0.29] 10[0.39] DB1Twin Distance plate cut-out DB1Twin Veneer cut-out Veneer Guide (Optional)
- Page 14 OPTION 3 - Veneer material can’t be conductor. 1. Check if the Veneer fits perfectly with the monitor. To join both parts correctly it is important that the two surfaces are touching each other in the whole length. If there is a gap between the Veneer and the monitor, check if the hole depth in the Veneer is correct.
- Page 15 OPTION 3 VENEER CUT-OUT DB2 Veneer cut-out AH10DB2 AH17DB2 AH22DB2 AH24DB2 "A" 258[10.15] 424[16.7] 518[20.39] 559,2[22] "B" 17[0.67] 20[0.78] 20[0.78] 20[0.78] "C" 8[0.31] 7,5[0.29] 7,5[0.29] 10[0.39] DB1Twin Veneer cut-out Veneer Guide (Optional)
