Assembly of double loop tunnel and
exits/entries of the free fall helix
19
46
A sse m b ly o f th e d o u b le
lo o p tu n n e l (fg . 46-49 )
1. T he looping diam eters depend
on the fall height of the steel
balls (see the ex am ple in
fg. 46-47)
2. All single loops of the loop
tunnels m ust be round and
hav e the sam e diam eter to
keep the steel balls running
sm oothly
48
20
50
A sse m b ly o f th e fre e fa ll
h e lix (e n trie s & e x its )
(fg . 50+ 5 1 )
1. Pay attention to a proper
installation of the entries and
ex its (fg. 50)
2. Install rails of entries and
ex its as show n in fg. 50
18
D ia m e te r
Height
Innerer Looping
Inner looping
D iam eter
Entry
Ex it
47
49
Parallel
D iam eter
51
Entry
Ex it
Ex it
Ex it
O uter looping
Parallel
Entry
