SpaceraiL Spacewarp Level 9.1 Instruction Manual page 12

Assembly of rails
16
R a il a sse m b ly ste p s
3. Please note page E4 for
stairw ay installation
4. From stairw ay (part B) to
seesaw A (fg. 27, 27-1+ 27-2)
5. From seesaw B to frst foor
elev ator entry BJ1 (fg. 27,
27-3)
Installation of stairw ay B
27-1
Please note fg. 27 , 27-1 and page E4 for
stairw ay installation
6. From seesaw A to seesaw B
(fg. 28, 28-1)
7. From the „bypass slip" to frst
foor elev ator entry BJ2
(fg. 28, 28-2)
A ssem ble rail as show n on the right
From seesaw A to seesaw B
28-1
Install 2 x 46cm rails (fg. 28+ 28-1)
12
27
From stairw ay (part B) to seesaw A
Seesaw A
28
From the „bypass slip" to frst foor elev ator entry BJ2
A tta ch th e se e sa w s a s sh o w n
Seesaw A
27-2
Install 2 x 90cm rails (fg. 27+ 27-2)
28-2
Install 2 x 93cm rails (fg. 28+ 28-2)
A tta ch th e se e sa w s a s sh o w n
Seesaw B
From seesaw B to frst foor elev ator entry BJ1
27-3
Install 2 x 100cm rails (fg. 27+ 27-3)
Seesaw B
28-3
