16
R a il a sse m b ly ste p s
8. Please note page E4 for
stairw ay installation
9. From shaft/arm AE-8 to
stairw ay (fg. 29, 29-2)
10. From free fall helix (ex it A ) to
frst foor elev ator entry BJ2
(fg. 29, 29-3)
Installation of stairw ay
29-1
Please note fg. 29, 29-1 and page E4
for stairw ay installation
11. From the junction B ex it to the
funnel-shaped helix (fg. 30,
30-1, 30-2)
12. From the „by pass slip" to
junction B entry (fg. 30, 30-3)
A ssem ble rail as show n on the right
From the junction B ex it to the funnel-shaped helix
30-1
Install 2 x 475cm rails (fg. 30, 30-1, 30-2)
29
From shaft/arm AE-8 to stairw ay
29-2
Install 1 x 550cm rails (fg. 29+ 29-2). Please note pag e
E 4 for stairw ay installation (fg. 24)
30
30-2
Ex it A
From free fall helix (ex it A ) to frst foor elev ator entry BJ2
29-3
Install 2 x 75cm rails (fg. 29+ 29-3)
Junction B
From the „bypass slip" to junction B entry
30-3
Install 2 x 55cm rails (fg. 30, 30-3)
Assembly of rails
13
