Assembly of rails
16
35
R a il a sse m b ly ste p s
21. From frst foor elev ator ex it
BJ3 to second foor elev ator
entry BI2 (fg. 35, 35-1)
22. From junction B v ia the loop
to frst foor elev ator entry BJ1
(fg. 35, 35-2, 35-3)
Caution: Steep dow nw ard
gradient! A ttach further rail
stands to prev ent steel balls
from m issing the track
From frst foor elev ator ex it BJ3 to
second foor elev ator entry BI2
35-1
Install 2 x 188cm rails (fg. 35, 35-1)
23. From junction A v ia the helix
36
to entry A of the free fall helix
(fg. 36, 36-1, 36-3)
24. From the tray [Ex 7] to entry B
of free fall helix (fg. 36, 36-2)
A ssem ble rail as show n on the right
From junction A v ia the helix to entry A of the free fall helix
36-1
Install 2 x 670cm rails (fg. 36, 36-1, 36-3)
16
From junction B v ia the loop to frst foor elev ator entry BJ1
35-2
Install 2 x 175cm rails (fg. 35, 35-2, 35-3)
Abzw eigung A
Junction A
36-2
Install 2 x 66cmrails (fg. 36, 36-2)
Junction B
Entry A
From the tray to entry B of free fall helix
35-3
Ca u tio n :Ste e p d o w n w a rd g rad ie n t! A tta ch fu rth e r rail sta n d s
to p re v e n t ste e l b alls fro m m issin g th e tra ck
T ray [Ex 7]
Eingang B
Entry B
36-3
