SpaceraiL Spacewarp Level 9.1 Instruction Manual page 14

Assembly of rails
16
31
R a il a sse m b ly ste p s
13. From second foor elev ator
ex it BI3 to „bypass slip"
(fg. 31, 31-1, 31-2)
14. From second foor elev ator
ex it BI3 to junction C (fg. 31,
31-3)
From second foor elev ator ex it BI3 to „bypass slip"
31-1
Install 2 x 86cm rails (fg. 31, 31-1, 31-2)
32
15. From junction C to pendulum
(fg. 32, 32-1)
16. From junction C to shaft/arm
AE-9 (fg. 32, 32-2, 32-3)
A ssem ble rail as show n on the right
From junction C to pendulum
32-1
Install 2 x 19cm rails (fg. 32, 32-1)
14
Junction C
31-2
Junction C
32-2
Install 2 x 194cm rails (fg. 32, 32-2, 32-3)
From second foor elev ator ex it BI3 to junction C
31-3
Install 2 x 16cm rails (fg. 31, 31-3)
Pendulum
From junction C to shaft/arm AE-9
32-3
