6Ch Mode:; 7Ch Mode: - Ayra Compar Kit Jr. User Manual

6CH Mode:

CH Function
1 Master dimmer
2 Strobe channel
3 Playback colour selection
4 Background colour selection
5 Show selection
6 Playback speed

7CH Mode:

CH Function
1 Master dimmer
2 Strobe channel
3 Dimmer red
4 Dimmer green
5 Dimmer blue
6 Dimmer white
7 Colour macros
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV
Value
000-255 (0-100%)
000-005 LED on
006-255 strobe slow-fast
000-255 colour selection
000-255 colour selection
000-030 Open
031-080 Show 1
081-105 Show 2
106-130 Show 3
131-155 Show 4
156-180 Show 5
181-205 Show 6
206-230 Show 7
231-255 Random show
000-249 speed, slow-fast
250-255 sound controlled mode
Value
000-255 (0-100%)
000-005 LED on
006-255 strobe slow-fast
000-255 (red 0-100%)
000-255 (green 0-100%)
000-255 (blue 0-100%)
000-255 (white 0-100%)
000-005 No function
006-013 Colour 1
014-021 Colour 2
022-029 Colour 3
030-037 Colour 4
038-045 Colour 5
046-053 Colour 6
054-061 Colour 7
062-069 Colour 8
070-077 Colour 9
078-085 Colour 10
086-093 Colour 11
094-101 Colour 12
102-109 Colour 13
110-117 Colour 14
118-125 Colour 15
126-190 Colour jump, slow-fast
191 No function
192-255 Colour fade, slow-fast
