Programming the flow meter

The unit of measurement and the correction factor can be programmed.
For programming, a button on the underside of the electronic counter is
actuated and kept switched on during the entire programming process. The
programming button is only accessible after the electronic counter has been
removed from the measuring chamber. To do this, the fastening screw on the
unit must be released.
1. By actuating the programming switch, the current statuses of the
correction factor and the unit of measurement are shown on the
display. Prior to programming for the first time, the following is
displayed:
- Correction factor = 0.0000
- Unit of measurement L
The correction factor can be programmed within the range of 0.0000 to
9.9999. The decimal point is always behind the first integer. This
decimal point is displayed as a point (.) with all units of measurement.
2. The sign for the unit of measurement flashes immediately after
actuating the programming button. All the other signs are displayed
constantly. Flashing indicates the value that can be modified. Every
time the RESET button is pressed, it switches to the next unit of
measurement in the following sequence (QT)-GAL-L-PT.
After selecting the required unit of measurement, this part of the
program can be exited from by pressing the TOTAL button. At the
same time, the unit of measurement selected in this way is saved as
the current value.
3. The value switched last is saved as the current value in the program
by pressing the TOTAL button.
4. Every time the RESET button is pressed, the value will switch by 1
larger, from 0 ... 9. The required value is saved in the program by
pressing the TOTAL button.
5. Completing the programming of the first place of the correction factor
by pressing the TOTAL button switches to programming the second
place of the correction factor. It flashes every 0.3 seconds. Every time
the RESET button is pressed, the value will switch by 1 larger, from
"0" to "9". The required value is saved in the program by pressing the
TOTAL button.
6. The procedure on programming the second place of the correction
factor described in Section e) is carried out in the same way for the
programming the remaining places.
7. If the required value was already set, you can immediately transition to
the next place by pressing the TOTAL button. The displayed, flashing
value is then saved in the program.
8. If programming is interrupted anywhere by enabling the programming
button, the new values entered so far and any old values that have not
been changed are adopted as the current programming status. The
