Item Description
1 Pressure hose
2 Suction hose
3 Suction screen
4 Ball valve
5 Flow meter
6 Filter
7 Motor-pump assembly
8 Clogging indicator
9 Air filters
10 Maintenance opening
11 Fluid level gauge
12 Tanks
13 Port for FCU
14 Bypass valve
15 Pressure relief valve
SE Drain
TE Drain
TS Suction port connection
TR Return line
S Suction side
P Pressure side
X Option
