Dimensions and Operating elements of the filter housing

Item Designation
1 Filter housing
2 Filter housing cover
3 Toggle screws
4 O-ring
5 Filter elements
6 Air-vent plug
7 Inlet flange DIN DN80
8 Outlet flange DIN DN80
9 Drain valve, clean side
10 Drain valve, dirt side
11 Clogging indicator
12 Element collet
MRF4
