Calculating the pressure loss of the filter housing / filter element

The total pressure of the filters at a specific flow rate is comprised of the
housing p ∆ and the filter element p
be determined using the following pressure loss curve. The pressure loss of
the filter elements is computed on the basis of the R factors.
p
∆ : Pressure loss curve, housing
Housing
The upper housing curve holds for mineral oil with a density of 0.86 kg/dm³
and a kinematics viscosity of 30 mm²/s. The lower housing curve holds for
water at 20°C. For turbulent flow, the differential pressure will change
proportionally to the density; for laminar flow, it will change proportionally to
the density and viscosity. The flow velocity may not exceed 3 m/s at the filter
inlet for oil and 4 m/s for water.
Filter element- p
∆ : pressure loss calculation, filter element
The following calculation is based on clean filter elements:
R
p bar
∆ ( ) =
MRF4
MoWa MRF4 3214670d en-us 2018-02-09.docx
V mm s Q l
× ( / ² ) × ( /
n L inch
× ( ) × 1000
en(us)
∆ . The pressure loss of the housing can
Flow rate (l/min)
R = R Factor
V = viscosity (mm²/s)
min)
Q = flow rate (l/min)
N = Numbers of elements
L = Length of element (inch)
Technical Description
