Summary of Contents for BZB Gear BG-UHD-18GFE
- Page 1 BG-UHD-18GFE 4K-HDR HDMI over Fiber USB KVM Extender User Manual...
-
Page 2: Table Of Contents
However, like all electronic equipment, the BG-UHD-18GFE should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
Users can readily extend Ultra-HD sources from DVD players, Blu-ray Disc player, PS4, PC, and any other HDMI sources broadcasting to distant display monitors including HDMI or DVI enabled TV sets or LCD PC monitors. Besides BG-UHD-18GFE is HDCP compliant, and supports IR& RS-232 pass-through path and keyboard/mouse USB signal transmission. -
Page 4: Specifications
SPECIFICATIONS Model Name BG-UHD-18GFE Technical BG-UHD-18GFE [Tx] BG-UHD-18GFE [Rx] Role of usage Transmitter [TX] Receiver [RX] HDMI compliance HDMI 2.0a HDCP compliance HDCP2.2 Video bandwidth Single-link 600MHz [18Gbps] Video support HDR 4K2K@60 (4:2:0 10bits) / 4K2K@60 (4:4:4 8bits) HDMI over fiber Audio support Surround sound [up to 7.1ch] or stereo audio... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS Transmitting unit ► BG-UHD-18GFE Front Panel USB[Host]: Connect to a USB port from the computer for keyboard & mouse control RS-232:Connect to serial port device with a DSUB-9 male-male or male-female cable here Mini USB: For technical support only [firmware update]... -
Page 6: Receiving Unit
Receiving unit ► BG-UHD-18GFE Front Panel USB[Device]: Connect to the USB keyboard & mouse RS-232:Connect to serial port device with a DSUB-9 male-male or male-female cable here Mini-USB: For technical support only [firmware update] Dip Switch DIP Switch Position Description TX &... -
Page 7: Connection Diagram
CONNECTION DIAGRAM... -
Page 8: Ir Pass-Through
IR PASS-THROUGH IR Extenders IR Blaster IR Receiver IR Sockets IR BLASTER: plug in the IR blaster to emit all IR command signals received from the IR receiver from the other end to control the devices corresponding to the IR signals. IR RECEIVER: plug in the IR receiver to receive all IR command signals from the IR remote controls of the corresponding devices. -
Page 9: Hdmi Pin Definition
HDMI PIN DEFINITION Type A (Receptacle) HDMI Pin 1 TMDS Data2+ Pin 11 TMDS Clock Shield Pin 2 TMDS Data2 Shield Pin 12 TMDS Clock– Pin 3 TMDS Data2– Pin 13 Pin 4 TMDS Data1+ Pin 14 Reserved (N.C. on device) Pin 5 TMDS Data1 Shield Pin 15... -
Page 10: Warranty
The SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the BG-UHD-18GFE features and specifications is subject to change without further notice. -
Page 11: Second Year Assurance
SECOND YEAR ASSURANCE BZB Gear wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*. Taking advantage of this program is simple, just follow the steps below: 1.
