Intended use:
This product is intended for use indoors in household and commercial usage areas.
Do not use outdoors.
Before installation, re-installation, cleaning, or troubleshooting:
• Stop the frame.
• Switch off the power supply and pull out the mains plug.
• Relieve the frame of any loads, which may be released during the work.
• Review the assembly instructions to confirm that the appropriate critical
components and accessories are being used with this product.
Before start-up:
• Make sure that the system has been installed as instructed in this User Manual
describing the motor system.
• Make sure that the voltage of the control box is correct before connecting the
system to the mains.
• Always use the supplied mains cable.
• System connection. The individual parts must be connected before connecting the
control box to the mains. See the User Manual for LINAK actuators, if necessary.
During operation
• If the control box makes unusual noise or smells, switch off the mains voltage
immediately.
• The maximum total load on the frame is 160 kg equally loaded, i.e. 80 kg on each
column. The 160 kg include the tabletop.
• Duty Cycle: 5 %, Max. 1 min./19 min. pause
• Take care that the cables are not damaged.
• Unplug the mains cable on mobile equipment before moving it.
• The products must only be used in an environment, that corresponds to their IP
protection.
Servicing of double-insulated products
In a double-insulated product, two systems of insulation are provided instead of
grounding. No grounding means is provided on a double-insulated product, nor is
a means for grounding to be added to the product. Servicing a double-insulated
product requires extreme care and knowledge of the system, and is to be done only
by qualified service personnel. Replacement parts for a double-insulated product
must be identical to the parts they replace. A double-insulated product is marked
with the words "Double insulation" or "Double insulated." The symbol (square
within a square)
is also able to be marked on the product.
