4. Mount cantilevers.
4.1. Place a cantilever slightly tilted at end of beam.
4.2. Press cantilever into place until a click is heard and pawls lock cantilever in correct position.
4.3. Mount cantilever in other end of beam.
Check that the cantilever is placed correctly and cannot be twisted off the DF2 beam.
Do not extract the beam using the cantilevers as handles.
5. Place assembled DF2 frame in correct position.
Use tape measure to ensure central placement of DF2 frame.
6. Fasten DF2 frame to tabletop using 20 mounting screws as follows:
6.a. 8 screws at ends of beam.
Use one of these to fix mains cable to beam with cable clamp creating a cable relief, see step 9.
Connect power cable.
6.b. 4 screws at extension points.
6.c. 8 screws in cantilevers.
c
a
c
b
Page 15 of 24
c
a
c
