About This Document; Scope; Safety Integrity Level - turck IM12-FI01-1SF-1R Safety Manual

1

About this Document

This safety manual contains all information that is required to operate the device in functional
safety systems. Read this manual carefully before using the device.
This document addresses only functional safety according IEC 61508. Other, e.g. intrinsic safety,
is not considered.
All instructions must be followed in order to assure functional safety.
Always make sure that this is the latest version of the safety manual at www.turck.com.
The English version is considered the definitive document. Care was taken in the production of
the translations of this document. If there is any uncertainty in its interpretation. Always refer to
the English version of the safety manual or contact Turck directly.
2

Scope

This safety manual is valid for the following devices:
Product Product Name
Number
7580200 IMX12-FI01-1SF-1R-PR/24VDC
7580201 IMX12-FI01-1SF-1R-0/24VDC
7580202 IMX12-FI01-1SF-1R-PR/24VDC/CC
7580203 IMX12-FI01-1SF-1R-0/24VDC /CC
7580220 IM12-FI01-1SF-1R-PR/24VDC
7580221 IM12-FI01-1SF-1R-0/24VDC
7580222 IM12-FI01-1SF-1R-PR/24VDC/CC
7580223 IM12-FI01-1SF-1R-0/24VDC /CC
In the following chapters the devices are divided
■
IMX12-FI01-1SF-1R
■
IM12-FI01-1SF-1R
3

Safety Integrity Level

The devices are rated to a SIL of
V01.00 | 2020/04
Number of
Channels
1
1
1
1
1
1
1
1
SIL 2
Terminal Block Design Power-Bridge-
Connection
screw clamps yes
screw clamps no
spring-type terminals yes
spring-type terminals no
screw clamps yes
screw clamps no
spring-type terminals yes
spring-type terminals no
Intrinsic Safety
yes
yes
yes
yes
no
no
no
no
5
