Parameterization

The user must select the parameters suitable for its safety application.
6.3.1

Parameters

The parameters are set using the switches on the housing side.
This is done with the help of a screwdriver.
If the teach button is pressed for 3 s, the parameters are adopted.
Sensor type
Selection
NAMUR
Switch
Voltage signal
3-wire PNP
3-wire NPN
Line monitoring (for NAMUR-sensors):
Selection
Off
Wire break and short circuit
Parameters:
Switch
S1
S2
S3
S4
S5
S6
S7
S8
14
Parameter
State
Line monitoring
OFF/ON
Relay mode
2P/4P
2P: Under/Overspeed
Under/Over
Relay diretion
Ninv/inv
Function Relay Loc
OFF/ON
Locked switching
LocOn/Locoff
SUD Input
[E2]/[E3]
SUD mode
Dyn/Stat
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Description
NAMUR sensor according to EN 60947-5-6
– 0-signal: sensor not actuated
– 1-signal: sensor actuated
Potential free contact
– 0-signal: switch open
– 1-signal: switch closed
Voltage signal:
– 0-signal 0...3 V
– 1-signal 5...30 V
3-wire sensor (positive, negative, positive)
– 0-signal: sensor not actuated (0 V)
– 1-signal: sensor actuated (12 V)
3-wire sensor (negative, positive, negative)
– 0-signal: sensor not actuated (12 V)
– 1-signal: sensor actuated (0 V)
Description
Line monitoring is switched off
Line monitoring short circuit and wire break
Comment
OFF/ON
(2-point)/(4-point)
Under-/Overspeed
(not inverted)/(inverted)
OFF/ON
Locked On/Locked Off
Input [E2]/input [E2]
Dynamic/Static
