Operation Instructions

6.1

General

The device must be registered online:
➤
registration card. This must be filled in with all required information upon receipt and sent to
Turck.
The device must only be carried out, fitted, installed, operated, commissioned and main-
➤
tained by trained and qualified personnel.
The device is not specified for a certain application. Make sure that application-specific as-
➤
pects are considered.
Data from other documents, e.g. data sheets, is not valid for functional safety operation. De-
➤
vices must be used in cabinets in an typical industrial field environment only. The following
restrictions describe the operation and storage conditions:
Ensure that the environment complies with the following ratings:
➤
Minimum ambient temperature
Maximum ambient temperature
Minimum storage temperature
Maximum storage temperature
Maximum air humidity
Minimum air pressure
Maximum air pressure
The average temperature over a long period of time directly on the exterior sidewall of the
➤
housing must be maximum 40 °C.
ū
The temperature on the exterior sidewall of the housing can deviate considerably from the
temperature in the control cabinet.
ū
The temperature on the exterior sidewall of the housing must be observed in a steady state.
ū
In case the temperature on the exterior sidewall of the housing is higher, the failure rates
from „5.3 FMEDA results" on page 9 must be adjusted:
For a higher average temperature of 60 °C on the exterior sidewall of the housing, the failu-
re rates are multiplied by an experience factor of 2.5.
Ensure that sufficient heat dissipation is provided.
➤
Protect the device from radiated heat and severe temperature fluctuations.
➤
Protect the device from dust, dirt, moisture, shock, vibration, chemical stress, increased
➤
radiation and other environmental influences.
Ensure a degree of protection of at least IP20 according to IEC 60529 at the mounting
➤
location.
Ensure that the electromagnetic stress does not exceed the requirements of IEC 61326-3.1.
➤
If there is a visible error, e.g. defective housing the device must not be used.
➤
During operation of the device, surface temperatures may occur that could lead to burns if
➤
touched.
The device must not be repaired. If problems occur with regard to functional safety, Turck
➤
must be notified immediately and the device must be returned immediately to:
Hans Turck GmbH & Co. KG
Witzlebenstraße 7
45472 Mülheim
Germany
The device must not stay in safe state longer than 24 h. If the cause of entering the safe state
➤
was not corrected the device must be replaced.
V01.00 | 2020/04
http://www.turck.com/SIL or with the supplied SIL
-25 °C
70 °C
-40 °C
80 °C
95 %
80 kPa
110 kPa
