Operation Instructions
6.2
Before operation
Fasten the device to a rail according to EN 60715 (TH35) as follows:
➤
Fig. 1:
Connect cables according to the wiring diagrams in
➤
Diagrams" on page
Use cables with terminal cross section
➤
ū
rigid: 0.2 mm
ū
flexible 0.2 mm
When wiring with stranded wires: Fix the wiring ends with ferrules.
➤
Connection via screw terminals
Insert the stripped cable ends (7 mm) in the guides of the cable glands.
➤
Fasten the screws with a screwdriver (max. tightening torque 0.5 Nm) to affix the cable ends.
➤
Fig. 2:
12
Fasten the device
20.
2
to 2.5 mm
2
or
2
to 2.5 mm
2
0.2...2.5 mm
2
(24...13 AWG)
7 mm
1
2
0.5 Nm
(4.43 LBS-inc)
Connection with screw terminals
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
„Appendix: Connection and Wiring
