turck IM12-FI01-1SF-1R Safety Manual page 16

Operation Instructions
BotOn/BotOff/TopOn/TopOff
These parameters represent the switching threshold for 2-point and 4-point switching modes.
The switching thresholds must not exceed the measuring range.
These parameters represent the switching threshold for 2-point switching modes:
Selection
BotOff
TopOn
BotOn
TopOff
BotOn
TopOff
BotOff
TopOn
These parameters represent the switching threshold for 4-point switching modes:
Selection
BotOff
BotOn
TopOn
TopOff
BotOn
BotOff
TopOff
TopOn
Locking function
This parameter depends on the physical state of the relay. Parameter "Inversion" is regarded.
Selection
Switched on
Switched off
Switching on/off delay
The value of this parameter specifies the switch on/off delay after detection of of switch on/off
condition.
Values between 0.05...75 s are possible.
Selection
On delay
Off delay
16
Mode
Under/NInv
Under/NInv
Over/NInv
Over/NInv
Under/Inv
Under/Inv
Over/Inv
Over/Inv
Mode
NInv
NInv
NInv
NInv
Inv
Inv
Inv
Inv
Description
The relay switches on according to the measured value and selected
configuration. It stays permanently locked on.
The locked state is left after power on reset or detection of a failure.
The relay switches off according to the measured value and selected
configuration. It stays permanently locked off.
The locked state is left after power on reset.
Description
The value of this parameter speci-
fies the switch on delay after detec-
tion of switch on condition.
The value of this parameter speci-
fies the switch off delay after detec-
tion of switch on condition.
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Switching point
G
G * (1 + H[%]/100 %)
G * (1 - H[%]/100 %)
G
G
G * (1 + H[%]/100 %)
G * (1 - H[%]/100 %)
G
Switching point
G * (1 - 1.2 * H[%]/100%)
G * (1 - H[%]/100%)
G * (1 + H[%]/100%)
G * (1 + 1.2 * H[%]/100%)
G * (1 - 1.2 * H[%]/100%)
G * (1 - H[%]/100%)
G * (1 + H[%]/100%)
G * (1 + 1.2 * H[%]/100%)
(Ex, NEx)
0.0, 0.5, 0.75, 1.0 s
0.0, 0.5, 0.75, 1.0 s
Range
0...f
max
< f
max
0...f
max
< f
max
0...f
max
< f
max
0...f
max
< f
max
Range
> 0
0...f
max
> 0
< f
max
