This section explains the replacement procedures of periodic replacement parts, main mechanical parts, and mounted
circuit boards.
2-1.

General Information for Parts Replacement

2-1-1.

Index

This section describes the replacement procedure of the parts below.
Mechanical parts
(4)
(3)
(2)
(1)
No. Part name
（1） Front Assembly
（2） LCD Module
（3） Top Cover
Main Board Assembly (for
（4）
CAMERA A)
（5） Main Board Assembly (for
CAMERA B)
Rear Panel Assembly
（6）
Mounted circuit boards
After replacing/repairing the mounted circuit boards (or the assembling parts including them), perform the steps after
replacement/repair. "1-11-1. Requirements on Replacement of Boards or Parts"
MCC-3000MT
Section 2

Replacement of Main Parts

(6)
(5)
Procedure
"2-3. KY-687 Board"
"2-4. LCD Module"
"2-2. Top Cover"
"2-6. Main Board Assembly (for CAMERA A)"
"2-7. Main Board Assembly (for CAMERA B)"
"2-14. Rear Panel Assembly"
2-1
