Product Description
The Special Edition AT8 ISF is a fixed frame screen hand-wrapped in velvet velour using EPV Screens
acoustically transparent front projection material designed for ultra-high-definition 4K/8K projectors.
The Sonic AT8 ISF material is ISF Certified for providing a flat spectral response and rendering
accurate colors in a dark room environment.
Sonic AT8 ISF
In order for the
list below for proper maintenance and cleaning.
• Use a soft bristle brush to spot clean for dust.
• Dip a soft bristle toothbrush in mild soap and water to clean light stains
•
Never rub or apply pressure when cleaning the surface.
•
Never attempt to use any solutions, chemicals, or abrasive cleaners on the screen surface.
•
To avoid damaging the screen, avoid touching it directly with your fingers, pens/pencils or any other
sharp or abrasive objects.
JA08112022
Special Edition AT8 ISF Series
Acoustically Transparent Fixed Frame Screen
For models/sizes above 150"
USER'S GUIDE – M Type
to maintain its projection qualities and optimum performance please refer to the
www.epvscreens.com
V 1.0
1
U-00256
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EPV Sonic AT8 ISF Series
Summary of Contents for EPV Sonic AT8 ISF Series
- Page 1 V 1.0 Product Description The Special Edition AT8 ISF is a fixed frame screen hand-wrapped in velvet velour using EPV Screens acoustically transparent front projection material designed for ultra-high-definition 4K/8K projectors. The Sonic AT8 ISF material is ISF Certified for providing a flat spectral response and rendering accurate colors in a dark room environment.
- Page 2 Frame Parts List A. Vertical Frame x 2pcs B. ½ Horizontal Frame x2 pcs C. ½ Horizontal Frame x 2 pcs Hardware Parts List M4*4 D5*4 M4*4 D5*4 Black 165” 180” Item Parts List 16:9 Center Joints- M4 (bottom position) Center Joints-D5 (top position) Elbow Joints M4 (bottom position) Elbow Joints D5 (top position)
- Page 3 Frame Assembly Step 1: Place the EPE sponge (foam) sheet on the ground of the area where the screen will be assembled. Step 2: Position the pieces of the frame on the EPE sponge in the arrangement shown below. Step 3: Insert center joint (a/b) connectors into one-half of the horizontal frame (B/C) and secure with the M4x7 screws (g) as shown in the illustration below.
- Page 4 Step 5. Secure the elbow joints by fastening them with M4x7 screws (g), 4 at each corner. Screen Material Step 6: Put on the white gloves (p) and carefully unroll the screen material on a clean surface from the roller to the other side as shown below.
- Page 5 Step 8: Insert the rods (r) through the sleeves according to their corresponding lengths on each edge of the screen as shown below. The short rods (top/bottom) will overlap to secure a firm grasp in the middle areas. (Black tips) Back Back Side Side...
- Page 6 Begin by first attaching all four corners, steps 1-4. Make sure all four corners are properly affixed before proceeding to attach the next springs. Continue to attach the remaining springs to the material in steps 5-12 in the follow order. JA08112022 www.epvscreens.com U-00256...
- Page 7 Step 10: Insert the Center Support Bar (o) into the upper top groove on the back of the frame with the bottom end near the approximate center point of the frame and rotate it in at an angle so that both ends of the bar are in alignment with the groove.
- Page 8 Step 13 Position the fixed frame screen onto the top of the bottom wall brackets (fig 1) as shown below and push down at the center of the top of the frame (fig 2) to secure. For Technical Support or an EPV Screens contact in your area, visit www.epvscreens.com...
