User Manual
IKORE B Transmitter
Technical description
IKORE B detailed description
Technical data
Description
Stop function
Ingress Protection rating
Anti-condensation system
Frequency band
Main mechanisms (maximum)
Range (Normal Conditions)
Auxiliary mechanisms
Removable EEPROM
Battery model
Battery life
Operating temperature range
Storage Temperature Range (24h)
Storage Temperature Range (long periods)
Relative Humidity
Weight (with battery)
Dimensions LxWxH mm
Harness
Display
Cable connector
Range limiter
Associated receivers
8 |
©
Danfoss | May 2021
Value
Cat. 3-Ple EN12849-1 and SIL 3 IEC 61508 / IEC 62061
IP65/NEMA4
N/A
2405MHz to 2475MHz 20dBm/100mW
Push button (7) + START+ STOP
100m
N/A
External
BT11K
8hr (100% duty cycle)
-20 °C to 70 °C (-4 °F to 158 °F)
-25ºC to 75ºC (-13ºF to 167ºF)
-25ºC to 55ºC (-13ºF to 131ºF)
max. 95% without condensation
315 grams
174.5x68x56
Hand strap/shoulder strap
N/A
N/A
N/A
R11
BC292582855621en-000201
