- Page 1 User Manual Remote Control IKORE B Transmitter www.danfoss.com...
- Page 2 User Manual IKORE B Transmitter Revision history Table of revisions Date Changed January 2019 Rebranded to Danfoss Power Solutions 0101 © Danfoss | January 2019 BC292582855621en-000101...
-
Page 3: Table Of Contents
User Manual IKORE B Transmitter Contents Safety instructions General safety....................................4 Safety warnings....................................4 Technical description Dimensions and identification..............................5 Startup........................................6 Maintenance Maintenance tips....................................7 Charger and battery BC70K and BT11K specifications..............................8 Setting up the BC70K battery charger............................8 BC70K status LEDs.................................... 9 Battery charging tips.................................. -
Page 4: Safety Instructions
Avoid knocking or dropping the product. • Do not use the product if a failure is detected. Changes or modifications not approved by Danfoss can void the user's authority to operate this product. Quick reference precautions Cr 1 Tx Cr 1... -
Page 5: Technical Description
User Manual IKORE B Transmitter Technical description IKORE dimensions and identification Dimensions in mm Status LEDs Hoist selection LEDs Maneuver push buttons STOP button External and extractable EEPROM module Alkaline batteries START push button Hoist selection push button © Danfoss | January 2019... -
Page 6: Startup
User Manual IKORE B Transmitter Technical description IKORE startup 1. Place the EEPROM and fully charged alkaline batteries or rechargeable battery if applicable. 2. Push and pull out the STOP button. The status LED will blink in blue until it reaches the stand-by mode and then it will turn into a fixed blue. -
Page 7: Maintenance
User Manual IKORE B Transmitter Maintenance IKORE B maintenance tips This product is designed for use in an industrial environment that may shorten the product's lifespan. Use these tips to maximize the lifespan of the product. • Use the hook/belt provided with the transmitter to prevent the transmitter from falling •... -
Page 8: Charger And Battery
User Manual IKORE B Transmitter Charger and battery BC70K and BT11K specifications BC70K battery charger Specification Value AC power supply 110-230V, 50/60 Hz, ± 10%, automatic switching DC power supply, nominal 12-24V BT11K battery Specification Value Voltage 3.7V Capacity 1130 mAh Li-ion Charging temperature 0°... -
Page 9: Bc70K Status Leds
User Manual IKORE B Transmitter Charger and battery BC70K status LEDs The BC70K has an LED for each compartment (BAT 1 and BAT 2) and a common indicator (POWER). Green LED; pulsing (BAT 1 and BAT 2) The battery is charging Green LED;... -
Page 10: Bc70K Battery Charger Dimensions
User Manual IKORE B Transmitter Charger and battery BC70K battery charger dimensions Dimensions in mm 2.57 97.15 103.31 10 | © Danfoss | January 2019 BC292582855621en-000101... - Page 11 User Manual IKORE B Transmitter © Danfoss | January 2019 BC292582855621en-000101 | 11...
- Page 12 Phone: +86 21 3418 5200 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequent changes being necessary in specifications already agreed.
