ASSEMBLY

TOOLS FOR THE MOUNTING OF THE BUILT-IN STOVE

¬ Spirit level
¬ Tape measure/foot rule

LOOSE PARTS

The following loose parts are located in the built-in stove's combustion chamber:
¬ Oven mitt
¬ Gasket for flue connecting piece
¬ Product registration number
¬ Brackets for baffles plates
Extra parts for Scan 5003-S:
¬ Type plate
¬ Calcium Silicate Surround
¬ Glue cartridge
¬ 10 Lamello P-14 - female
¬ 10 Lamello P-14 pre-load clips
¬ 4 Brackets
¬ 30 Metal pins
¬ 4 Adjustment screws
¬ 4 Washers Ø5 3/20x1,5 (HV140)

ADDITIONAL ACCESSORIES

¬ Floor plates (see page 9)
¬ Heat-storage stones (see page 14)

DISPOSAL OF PACKAGING

Your Scan built-in stove may come supplied with the following packaging:
Wood packaging
Polystyrene top
Foam
Plastic bags
Stretch/plastic film

LOAD-BEARING FOUNDATION

All items in our product range come under the category of lightweight fireplaces and stoves and do not normally require any
reinforcement of the beam structure. They can be positioned on ordinary beams/floor.
You should of course make sure that the foundation on which the stove is positioned can indeed support the weight of the stove
and, where applicable, a steel chimney, if you have opted for this solution. In case of doubt about the carrying capacity of the
floor, please consult a building expert.
8
The wood packaging can be reused and after final use can be incinerated as a CO
product or sent for recycling.
Send for recycling or waste disposal.
Send for recycling or waste disposal.
Send for recycling or waste disposal.
Send for recycling or waste disposal.
¬ Cordless electric drill
¬ Rubber hammer
¬ Flue connection piece
¬ Screws for fastening the flue connection piece
¬ Combustion chamber lining
¬ Eco energy label
¬ Steel base
¬ 1 l. primer
¬ 10 Lamello P-14 - male
¬ 1 Tenso P-14 pre-load tool
¬ 4 M5x10 screws
¬ 98 Screws Ø4x25/Ø8 (PAN TX20)
¬ 4 Steel bars
¬ Fresh air box Ø149 cm (see page 12)
¬ Heat shields/convection covers (see page 15)
neutral
