2.2 Installing the XDS560v2 STM JTAG Emulator
The next three sections describe the steps for installing the XDS560v2 STM JTAG
Emulator to interface to a PC or laptop via ethernet or USB.
Target Cable Connectors:
Be very careful with the target cable connectors. connect them gently; don't force
them into position, or you may damage the connectors.
Do not connect or disconnect the emulator tail while the target system is powered up.
Installing the XDS560v2 STM JTAG emulator is a three step process:
2.2.1 Installing Code Composer Studio Software
Code Composer Studio should be installed before starting the hardware installation.
Please refer to the separate software Installation guide for the installation of Code
Composer Studio and XDS560v2 STM device drivers.
If you are doing a custom driver installation make sure the CD ROM is installed in the
CD-ROM drive on your PC.
2.2.2 Configuring the Emulator Tail
The emulator tail is the physical interface between the emulator and target board. The
tail configuration will consist of 3 parts:
WARNING !
1. Installing the Code Composer Studio software
2. Configuring the emulator tail with correct target adapter
3. Installing the USB or Ethernet connection to the host PC
A - Emulator tail header
B - Emulator tail header to MIPI 60 pin adapter
C - MIPI 60 to target JTAG connector adapter
MIPI 60 to 20 pin CTI - installed at the factory
MIPI 60 to TI 14 pin
MIPI 60 to TI 60 pin
MIPI 60 to ARM 20 pin
Spectrum Digital, Inc
2-3
