Model: Martini-C3
Subject:
Differences between the MT-C3.5 and MT-C3
From:
2nd Tech Support Sec. Service Support Dept.
Classification:
Differences between the MT-C3.5 and MT-C3
Overview
The MT-C3.5 (D052/D053/D054) is basically the MT-C3 with some minor changes applied.
The mechanical parts, controller, and machine layout are the same. There are only four
differences, which are listed below:
1. CPM
Each version of the MT-C3.5 is five copies/minute faster than its MT-C3 predecessor. This
was achieved not by increasing the printing speed, but by reducing the paper interval
(firmware modification).
The following table shows the paper intervals when continuously printing A4/LT-LEF
sheets on each model, along with their printing speeds:
CPM
Type a
55
Type b
65
Type c
75
2. Cleaning brush rotation speed
The number of rotations is the same on the MT-C3.5a/b, but on the MT-C3.5c, the rotation
speed was increased by 50%. This was in order to prevent blurred images caused by OPC
filming. As a result, the brush can more easily wipe foreign particles off the drum surface.
The increase in speed was achieved by modifying the mainframe gears (MT-C3.5 Parts
Catalog, pg. 121, items 14 and 16).
Note: The differences between the mainframe gears on the MT-C3.5a/b and MT-C3.5c
are the color and P/N.
-
MT-C3a/b/c, C3.5a/b: Black
-
MT-C3.5c:
T
echnical
Troubleshooting
Mechanical
Paper path
Product Safety
MT-C3
Printing
Paper interval
speed
(A4/LT)
270mm/sec
81.9/75.9mm
362mm/sec 121.6/115.6mm
362mm/sec
77.7/71.7mm
White
B
ulletin
Date:
29-Jan-08
Prepared by:
Part information
Electrical
Transmit/receive
Other (
)
Printing
CPM
speed
60
270mm/sec
70
362mm/sec
80
362mm/sec
AB011482, AB017640
AB011507, AB017760
PAGE: 1/3
No.:
RB246026
S. Watanabe
Action required
Service manual revision
Retrofit information
MT-C3.5
Paper interval
(A4/LT)
57.8/57.5mm
98.1/92.1mm
59.8/53.8mm

Advertisement

loading
Need help?

Need help?

Do you have a question about the Martini-C3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ricoh Martini-C3

  • Page 1 PAGE: 1/3 Model: Martini-C3 Date: No.: 29-Jan-08 RB246026 Subject: Prepared by: Differences between the MT-C3.5 and MT-C3 S. Watanabe From: 2nd Tech Support Sec. Service Support Dept. Classification: Troubleshooting Part information Action required Mechanical Electrical Service manual revision...
  • Page 2 PAGE: 2/3 Model: Martini-C3 Date: No.: 29-Jan-08 RB246026 3. Elimination of the fusing lamp for side heating The lamp for side heating (listed in the MT-C3 Parts Catalog on pg. 99, item 28) was eliminated on the MT-C3.5c. This is because the warm-up time on this model (60 sec.) is 30 seconds slower than on the MT-C3 (30 sec.), and as a result, there is no need to...
  • Page 3 PAGE: 3/3 Model: Martini-C3 Date: No.: 29-Jan-08 RB246026 4. Firmware modifications It is possible to use the same firmware on both MT-C3 and MT-C3.5 models, except for the Engine firmware (the MT-C3 and MT-C3.5 both have their own unique Engine firmware).
  • Page 4: Peripheral/Option Summary Table

    February 2008 1.1.5 PERIPHERAL/OPTION SUMMARY TABLE The table below summarizes all the peripheral devices and controller options that can be installed with the B064, B140, and B246 Series machines. O: YES, X: NO Series Bnnn Name Class* Comment B064 B140 B246 B328 Copy Connector Kit...
  • Page 5 February 2008 Series Bnnn Name Class* Comment B064 B140 B246 B660 Z-folding Unit ZF Installed with B674, B700, or 4000 B701. B674 Booklet Finisher Punching, sorting, shifting, corner/booklet stapling. B679 IEEE1284 Interface Board Board Type A B700 SR 4000 Punching, sorting, shifting, corner/booklet stapling.
  • Page 6 February 2008 Class 1: Peripheral units connected directly to the mainframe Class 2: Components installed on or in peripheral units (punches, etc.) Class 3: MFP controller options (SD cards, boards)
  • Page 7 February 2008 1.26 FAX OPTIONS: B246 SERIES 1.26.1 FAX OPTION TYPE 7500 (B819) ACCESSORY CHECK Check the quantity and condition of the components against the following list. Description Q’ty Interface Board Keytop (NA) Keytops (Symbol) Ferrite Core Screws (Blue M3 x 6) Fax Connector Bracket Super G3 Decal Instructions...
  • Page 8 February 2008 Installation Procedure FCU installation CAUTION Before installing this fax unit: 1) Print out all data in the printer buffer. 2) Turn off the main power switch and disconnect the power cord and the network cable. B819R102.WMF 1. Disconnect the ADF connector [A]. 2.
  • Page 9 February 2008 B819R103.WMF 4. Remove the controller box cover [A] ( x13). 1-207...
  • Page 10 February 2008 B819R104A.WMF 5. Remove the option board cover [A] ( x2). 6. Remove the option faceplate [C] ( x3). 7. Remove the cover plate [D] ( x1). 1-208...
  • Page 11 February 2008 B819R105.WMF 8. Attach the interface board [A] ( x3). 1-209...
  • Page 12 Important: If the jumper remains at the OFF position this will cause SC672 (Controller Startup Error) to appear. 10. Attach the FCU [B] to the interface board ( x4). 11. Press on the "RICOH" logo at [C] to confirm that the MBU is securely mounted on the FCU. 1-210...
  • Page 13 February 2008 B819R107.WMF 12. Attach the speaker [A] to the side of the controller box ( x2). 13. Connect the speaker harness [B] to CN605 on the FCU ( x2). 1-211...
  • Page 14 February 2008 B819R108A.WMF 14. Reattach the option board cover [A] removed in Step 5 ( x2). 15. Reattach the option faceplate [B] removed in Step 6 ( x3). 16. Attach the fax connector bracket [C] ( x1). NOTE: Make sure that the protective sleeves [D] and [E] are attached properly. 1-212...
  • Page 15 February 2008 B819R109.WMF 17. Connect the small end of the FCU power harness [A] to CN323 18. Set the large end of the harness [B] into the vertical cutout [C]. 1-213...
  • Page 16 February 2008 B819R110.WMF 19. Remove the screws of the controller box [A] then open it ( x4). 20. Connect one end of the FCU power relay harness [B] to CN121 on the PSU x1). 21. Connect the other end of the FCU power relay harness [C] to the harness connector set in the vertical cutout at (the connector set in Step 18) ( x1).
  • Page 17 February 2008 B819R111A.WMF 22. Remove the blank keytop [A] (5th from the top) and replace it with one of the keytops provided [B] (either the "Facsimile" keytop or the fax symbol keytop). 1-215...
  • Page 18 February 2008 B819R112A.WMF 23. Attach the "Super G3" decal to the front door. 24. Attach the FCC and serial number decals to the rear cover of the machine.. NOTE: The FCC decal is for the U.S. and Canada only. 1-216...
  • Page 19 February 2008 Line Connection and Check B819R113.WMF 1. Loop one end of the telephone cable [A] once, then enclose it with the ferrite core [B] as shown. NOTE: Attach the ferrite core at least 9 cm (3.5 in.) from the connector. LINE B819R114.WMF 2.
  • Page 20 February 2008 5. Go into the SP mode and confirm that the fax SP codes are enabled. • Push [Reset], enter "107", then hold down "Clear/Reset" for at least 3 sec. • At the initial screen, confirm that "Fax SP" is displayed. This indicates that the machine recognizes the fax unit.
  • Page 21 February 2008 1.26.2 G3 INTERFACE UNIT TYPE 7500 (B820) ACCESSORY CHECK Check the quantity and condition of the components against the following list. Description Q’ty G3 Interface Board (attached) G3 Interface Unit* CCU Drive Board CCUIF Harness Screws (Blue M3 x 6) G3 Connector Bracket FFC (Flat Film Connector) Telephone Cable (NA Only)
  • Page 22 February 2008 Installation Procedure G3 Board Installation CAUTION Before installing this optional unit, 1) Print out all data in the printer buffer. 2) Turn off the main switch and disconnect the power cord and the network cable. B820R102.WMF 1. Disconnect the ADF connector [A]. 2.
  • Page 23 February 2008 B820R103.WMF 4. Remove the controller box cover [A] ( x13). B820R106.WMF 5. If installing single-line G3, remove only one blind cover -or- If installing dual-line G3, remove two blind covers NOTE: Make sure the protective sleeve [A] is attached properly. 1-221...
  • Page 24 February 2008 B820R105.WMF 6. Connect the FFC [A] (Flat Film Connector) to the CCU drive board [B]. Important: Connect the FFC with the green, insulated side visible and the bare connector strip down so it touches the connector strip of the board. 7.
  • Page 25 February 2008 B820R106.WMF 9. Attach the connector bracket to the G3 expansion board ( x1). 10. If one G3 line is being installed, attach the connector bracket as shown on the left.. -or- If two G3 lines are being installed, attach the connector brackets shown on the right.
  • Page 26 February 2008 B820R109.WMF B820R108.WMF 12. Attach the G3 interface unit ( NOTE: The illustration on the left shows the single G3 board installation and the illustration on the right shows the dual G3 board installation. B820R110.WMF B820R111.WMF 13. Connect the CCUIF harness to the CCU drive board and CCU I/F NOTE: The illustration on the left shows the single G3 board installation and...
  • Page 27 February 2008 Line Connection and Settings B819R113.WMF 1. Loop one end of the telephone cable [A] once, then enclose it with the ferrite core [B] as shown. NOTE: • Attach the ferrite core at least 9 cm (3.5 in.) from the connector. •...
  • Page 28 February 2008 5. Do these communication switch settings: SP1104-23 (Switch 16) Set Bit 1 "1". Set Bit 3 "1" if two G3 boards are installed. 6. Exit the Service Mode and cycle the machine off/on with the main power switch. 7.
  • Page 29 If the error persists, format the Only the HDD was replaced with an HDD unit HDD with SP5832-004. from another machine. SC876-99 Cause unknown. The error occurred at power Contact Ricoh design section. on or while the machine was operating. 4-32...
  • Page 30: General Specifications

    February 2008 7. SPECIFICATIONS 7.1 GENERAL SPECIFICATIONS 7.1.1 COPIER Configuration Console Original Sheet/Book/Objects Original Size Max. A3/11" x 17" Min. B5 SEF/5.5" x 8.5" (using ADF) Original Alignment Rear left corner Copy Paper Size Paper tray, Duplex A3/11" x 17" – A5 SEF/5.5" x 8.5" By-pass tray A3/11"...
  • Page 31 February 2008 Warm-up Time B064/B065 Less than 300 s from Off mode (under 20°C room temp.) Less than 25 s from low power mode B140/B141/B163/B142/B143/ Less than 30 s B228/B246/B248/B249/B250/ B252/B253/D052/D053 D054 Less than 60 s Continuous Copy 1 ~ 999 (Operation panel entry) Paper Capacity Tray 1 (tandem tray) 3100 sheets...
  • Page 32 February 2008 7.1.2 ADF Original Size A3/11" x 17" – B6/5.5" x 8.5" Original Weight 1-sided original 40 ~ 128 g/m (11 ~ 34 lb.) 2-sided original 52 ~ 128 g/m (14 ~ 34 lb.) Table Capacity 100 sheets (80 g/m , 20 lb.) or less than 12 mm (0.4") original stack height Original Standard Position...
  • Page 33: Power Consumption

    February 2008 7.1.3 POWER CONSUMPTION B064/B065 Copier (120V Model) Mainframe Only Full System Warm-up Approx. 1.20 kW Approx. 1.25 kW Stand-by Approx. 0.30 kW Approx. 0.32 kW Copying Approx. 1.55 kW Approx. 1.65 kW Maximum Less than 1.60 kW Less than 1.70 kW B064/B065 Copier (220V to 240V Model) Mainframe Only Full System...
  • Page 34 February 2008 Noise Emission: Sound Power Level B064 (60 CPM) B065 (75 CMP) Mainframe Only Standby Less than 48 dB (A) Less than 48 dB (A) Copying Less than 71 dB (A) Less than 71 dB (A) Complete System Standby Less than 49 dB (A) Less than 49 dB (A) Copying...
  • Page 35 February 2008 Noise Emission: Sound Pressure Level B064 (60 CPM) B065 (75 CMP) Mainframe Only Standby Less than 38 dB (A) Less than 38 dB (A) Copying Less than 57 dB (A) Less than 57 dB (A) Complete System Standby Less than 39 dB (A) Less than 39 dB (A) Copying...
  • Page 36: Machine Configuration

    February 2008 7.2 MACHINE CONFIGURATION B246V500.WMF Item Machine code Number Mainframe B246 B248 B140 B065 B249 B141 B064 D052 B163 D053 D054 A3/DLT Kit B475 ○ ○ ○ Inside mainframe Tab Sheet Kit B499 ○ ○ ○ LCT (Large Capacity Tray) B473 ○...
