Measuring procedure
1. PHOTO MEASURMNENT
a. Apply a reflective mark to the object being measured. Slide
the function switch to "rpm photo" position.
b. Depress the MEASURE BUTTON and align the visible light
beam with the applied target. Verify that the MONITOR
INDICATOR lights when the target aligns with the beam.
2. CONTACT TACH MEASUREMENT
a. Slide the FUNCTION SWITCH to "rpm contact" position.
Install the proper RPM ADAPTER on the SHAFT.
b. Depress the MEASURING BUTTON and lightly pressing the
RPM ADAPTER against the center hole of rotating shaft. Be
certain to keep alignment straight. Release the MEASURING
BUTTON when the display reading stabilizes.
3. SURFACE SPEED MEASUREMENT
a. Slide the FUNCTION SWITCH to "m/min contact" position.
Install the SURFACE SPEED WHEEL on the SHAFT instead
of the RPM ADAPTER.
b. Depress the MEASURING BUTTON and simply attaching
©Copyright Abacanto Digital SA.
Manual de usuario AD6236P
AD Instruments
25
