AD Instruments
_______________________________________________________________________________
PHOTO TACHOMETER
Measuring Range: 2.5 to 99999RMP
Resolution: 0.1RPM (2.5 to 999.9RMP)
1RPM (over 1000RPM)
Total Test Range: 1 to 99999
Panel description:
A: Reflective mark
B: Signal light beam
C: Measure button
D: Function switch
E: Memory call button
F: Display window
G: Battery cover
Measuring procedure
1. PHOTO RPM MEASUREMENT
a. Apply a reflective mark to the object being measured. Slide
the function switch to " RPM" position.
b. Depress the MEASURE BUTTON and align the visible light
©Copyright Abacanto Digital SA.
18
Manual de usuario AD6236P
