3. Layout, Connections & Limitation of Connection
3.1 Layout
1x USB 3.2 (Gen1)
Downstream A-Port
3.2 Connections
5V Connector:
USB 3.2 (Gen1) A-Port:
StdB_SSTX +
StdB_SSTX -
VCC
© Copyright 2020 by EXSYS Vertriebs GmbH. All Rights Reserved
5V Buchse for
optional external
Power Supply
ATTENTION!!!
Use only with optional available Power Supply!
GND_DRAIN
StdB_SSTX+
StdB_SSTX -
GND
D-
D+
1x USB 3.2 (Gen1)
Upstream B-Port
Attention!
Never plug in with force
or in wrong direction.
10
EX-1452IS
Power LED
