Edition 06/2006
The visual feedback with the green, amber and red LED's is always active. It is possible to activate
the audible feedback by putting ST1 jumper on (see page 8). Les indications sonores sont émises en
même temps que l'affichage lumineux.
Description Désignation
4
DIAX® screw – M5x16
1
M5 DIAX® spanner
1
05D 680K varistor
Dimensions:
MOUNTING KIT
- Front plate: 120H x 95W x 2D (mm)
- Back casing: 105H x 80W x 45D (mm)
CAASE
B
-
K
ACK
LIT
EYS
100
USER CODES
PORTE
DIGICODE
K
EYPAD
– F
M
LUSH
OUNT
Rating
IP 54
Schéma
1
Advertisement
Table of Contents
Related Manuals for CDVI CAASE
Summary of Contents for CDVI CAASE
- Page 1 Edition 06/2006 CAASE EYPAD – F USER CODES LUSH OUNT The visual feedback with the green, amber and red LED’s is always active. It is possible to activate the audible feedback by putting ST1 jumper on (see page 8). Les indications sonores sont émises en même temps que l’affichage lumineux.
-
Page 2: Product Information
Edition 06/2006 I. PRODUCT INFORMATION A. SPECIFICATIONS Input voltage 12V to 24 VAC 12V to 48 VDC 12-digit backlit keys keypad Visual feedback (Green, Amber and Red LED’s) EPROM memory storage 100 user codes programmable in 4 to 6-digit code lengh 2 relay outputs N/O and N/C contact 8A @ 250V 1 relay output N/O contact 6A @ 250V Master code programmable in 4 to 6-digit code lengh... -
Page 3: Programming A New Master Code
Edition 06/2006 II. PROGRAMMING A. Erase Keypad Memory / Reset Keypad to Factory Default Values 1. Enter the master code twice (12345 default value master code). 2 beeps are emitted to confirm entry in programming mode. 2. Press A6. The green LED lights on during 1 second. Press on A B to start the reset. -
Page 4: Programmation Des Codes
Edition 06/2006 D. Programmation des codes Group1: from user number 00 to 59, relay 1 Group 2: From 60 to 79, relay 2 Group3: from user number 80 to 99, relay 3 Master Code Master Code Red LED lights To add a user code: ... - Page 5 Edition 06/2006 E. Programmation des temporisations 1. Enter the master code twice (12345 default value master code). The red LED lights on to confirm entry in programming mode. 2. Press A0 to program the key-in keypad time and the backlit keys time. The green LED’s light during 1 second.
- Page 6 Edition 06/2006 H. Programming a Sub Master Code 1. Enter the master code twice (12345 default value master code).The red LED’s light on to confirm entry in programming mode. 2. Press A7 to enter in sub master code menu of group 1. The green LED lights on during 1 second. Enter the new sub master code.
- Page 7 Edition 06/2006 CAA/SE WIRING DIAGRAM P2: Reset P3: Enable/disable user code modification by user ST1: Audible feedback jumper Remove to disable audible feedback C3 T3 P1 M H1 R2 C2 T2 R1 C1 T1 Input Voltage 12V to 24VAC 230V or 12V to 48VDC PSU for a device V: Varistors...
- Page 8 Edition 06/2006 CAA/SE TEMPLATE Scale 1 : 1...
