Kemlan Horizon 700 Low Line Installation Instructions Manual
Three sided natural draft electronic ignition gas fireplaces
Hide thumbs
Also See for Horizon 700 Low Line:
- Installation instructions manual (14 pages) ,
- Installation instructions manual (15 pages)
Related Manuals for Kemlan Horizon 700 Low Line
Summary of Contents for Kemlan Horizon 700 Low Line
- Page 1 Installation Instructions Horizon Three Sided Natural Draft Electronic Ignition Gas Fireplaces 25/02/2021 24/08/2017 Ver. 1 Ver. 1...
-
Page 2: Location Requirements
Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces SUITABLE GAS BURNER OPTION Model Type 2: Natural Draft Electronic Ignition Gas Fireplace SINGLE SIDED MODELS 1100 Edge 1000 Mk2 Pebble DATA PLATE: Refer to information on page 13 of this... -
Page 3: Before Installation
• An Australian approved cowl is required at flue unused outlet must remain uncapped. terminal. Cowls are made from ss304 2b materials. 13 Vent (240mm x 90mm) supplied by Kemlan is • Refer to the table below for flue diameter and flue required to ventilate chase to room cowl size. -
Page 4: Assembly Requirements
Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces ASSEMBLY REQUIREMENTS : THREE SIDED MODEL SHOWN DOUBLE SKIN FLUE (SIZES VARY DUE TO MODEL ) CEILING IMPORTANT: BOTH COMBUSTIBLE CAPS NEEDS TO STAY FRAMING OFF, IF HEAT ZONE IS... - Page 5 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces Measurement and Specification of NDEI USE EYELETS TO SUPPORT OPEN END TO FRAME ABOVE HORIZON THREE SIDED : DETAIL Z NOTE: GLASS ONE SIDE IS OPTIONAL CEMENT SHEETING UNDER THREE SIDED 10”...
- Page 6 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces Measurement and Specification of NDEI FRONT OF FIREPLACE SECTION VIEW DETAIL Y - LIP TRIM ASSEMBLY USE EYELETS TO SUPPORT OPEN 25mm END TO FRAME ABOVE 110mm Min. +/- 285mm 150mm 150mm Min.
- Page 7 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces DRILL THROUGH THE BEAM , RAFTER OR FRAMING IF REQUIRED AND PUSH THROUGH THE THREADED ROD. THREADED ROD EYELET MAKE SURE THESE PLANES ARE PARALLEL, AND MAKE SURE ALL CORNERS ARE SQUARE •...
- Page 8 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces HEAT ZONE CONVERSION CASING ACTIVE FLUE STANDARD VENT FULL WELD HOLES IMPORTANT: BOTH HEATZONE CAPS NEED TO STAY OFF, IF UNIT IS NOT VENTED INTO A ROOM SECTION A-A...
- Page 9 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces SECTIONS AUSTRALIAN APPROVED CEILING WITH 25MM GAS COWL AIR SPACE TO OUTER FLUE,REQUIRED TO SEAL CHASE APPROVED FLASHING CEILING 25MM MIN. FLUE CLEARANCE TO TIMBER FRAMEWORK AND 10MM WALL...
- Page 10 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces HEAT ZONE CONVERSION IMPORTANT: IF HEATZONE KIT IS USED, UNUSED OUTLET MUST REMAIN UNCAPPED CEILING SW 1 SW 2 2 x10 amp GPO’S Fireplace ON/OFF Switch Optional Heat zone ON/OFF Switch...
- Page 11 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces KEMLAN INDUSTRIES 13 FRENCH SERIAL No. xxxx AVENUE BRENDALE IAPMO No. GMK10737 QLD 4500 MODEL: MODEL NO. GAS TYPE BURNER GAS CONS. GAS CONS. INJECTOR INJECTOR T.P.P. T.P.P. HORIZON RANGE...
-
Page 12: Gas Installation
Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces Laying the fire – Gas Installation Coal & Pebble Check unit is suitable for intended gas supply. Note position on gas appliance on drawing • Evenly spread a bag of Vermiculite into the burner specification on right hand side of appliance. - Page 13 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces Laying the fire – Coal & Pebble MARK 2 COALS 700/800 – 600 X 155 MARK 2 PEBBLES 700/800 – 600 X 155 MARK 2 COALS 1000 – 992 X 135 MARK 2 PEBBLES 1000 –...
- Page 14 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces Laying the fire - 850 Ceramic Log P O S I T I O N I N G O F A L L L O G S • It is important to follow the log recommended 2 .
- Page 15 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces Laying the fire – 700 Ceramic Log P O S I T I O N I N G OF A L L L O G S • It is important to follow the log recommended positioning.
- Page 16 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces Laying the fire - 700 Ceramic Log 4 . LOC ATE LOG NO. 4. 6 . L O C AT E L O G N O. 7 This log is placed with the thinner edge on the The charred effect of the log is positioned on the smaller coal.
-
Page 17: Commissioning Procedure
• Operation of other gas appliances E The gas burner is designed to work in a Kemlan • Operation of optional appliance fan at any speed. Horizon electronic power flue ignition system. Should any spillage be detected the cause must be Working correctly there will be no spillage. - Page 18 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces TAIS 00-L140-D5-000V For further service information contact Kemlan Australia Head Office –13 French Avenue, Brendale, Queensland 4500 Telephone –PH: (07) 3490 5500 25/02/2021 Ver. 1...
- Page 19 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces Service Instructions for Direct Ignition and Power Flue Horizon fireplaces. POWER FLUE SERVICE INSTRUCTIONS PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION PILOT WILL NOT LIGHT WITH FAN - CHECK FOR GAS SUPPLY AND TURN ON...
- Page 20 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces DIRECT IGNITION PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION - CHECK FOR GAS SUPPLY AND TURN ON ALL CONNECTIONS PILOT WILL NOT LIGHT 1) NO GAS - CHECK GAS PRESSURE - CHECK PILOT AND CLEAN INJECTOR...
- Page 21 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces Trouble shooting guide for Techrite ignition pack Warning: This is a 240VAC module. All connections to the module are 240V (except ignition cable and flame sense). Ensure power is switched off before checking any connection or replacing any components.
- Page 22 Installation Instructions Kemlan Three Sided Natural Draft Electronic Ignition Gas Fireplaces Flash Code Meaning Possible Cause (Red LED) Pressure switch fail Check combustion fan. Check unit has started and pressure switch and connections. during heat cycle the Check flue for obstructions...
-
Page 23: This Warranty Does Not Cover
WARRANTY FOR HORIZON MODELS Provided the appliance has been correctly installed according to instructions, Kemlan guarantee the cost of replacing parts and the labour in connection therewith for a period of 12 months from the date of installation. THIS WARRANTY DOES NOT COVER –...
