- Page 1 Installation Instructions Horizon 3 Sided Fireplaces...
-
Page 2: Ventilation Requirements
Installation Instructions Kemlan Natural Draft Electronic Ignition 3 Sided Gas Fireplaces Natural Draft Electronic Ventilation Requirements: Ignition approved for the Rooms with gas open fires require fresh air vents a per following models: gas regulations. For example: 1 x VENT REQUIRED... -
Page 3: Before Installation
Installation Instructions Kemlan Natural Draft Electronic Ignition 3 Sided Gas Fireplaces Before Installation Installation The Natural Draft Electronic Ignition (N.D.E.I.) flue 1. The N.D.E.I. system is supplied with all required system shall be installed by authorized personnel electrical fittings. Work needs to be undertaken by a in accordance with the manufacturer’s installation... - Page 4 Installation Instructions Kemlan Natural Draft Electronic Ignition 3 Sided Gas Fireplaces ALL STRUCTURAL WORK TO ARCHITECTS DESIGN Measurements and Specification of NDEI THREE SIDED 150mm min 80mm 25mm 108mm 60mm min 150mm Ventilation required under. 60mm Min 10 FC Sheet. Minimum 5 x 50mm holes in sheet between framing.
-
Page 5: Frame Details
Installation Instructions Kemlan Natural Draft Electronic Ignition 3 Sided Gas Fireplaces ALL STRUCTURAL WORK TO ARCHITECTS DESIGN Sections Front 10mm Sheeting O.D Frame Clearance to flue min 25mm -Including Sheet 80mm REFER FRAME DETAILS Vented under min 25mm 12mm Ventilation required under. - Page 6 Installation Instructions Kemlan Natural Draft Electronic Ignition 3 Sided Gas Fireplaces ALL STRUCTURAL WORK TO ARCHITECTS DESIGN Power Flue Internal Kit Gas Cowl Trim to suit Cut pipe Silencer Unit Internal Power Flue Components 1. 1x REDUCER - STAINLESS STEEL - size as above - 150mm 2.
- Page 7 Installation Instructions Kemlan Natural Draft Electronic Ignition 3 Sided Gas Fireplaces ALL STRUCTURAL WORK TO ARCHITECTS DESIGN Power Flue External Kit Silencer Unit External Power Flue Components 1. 1x REDUCER - STAINLESS STEEL - size as above - 150mm 2. 1x ATTENUATOR - ZINCANNEAL 3.
-
Page 8: Location Requirements
Installation Instructions Kemlan Natural Draft Electronic Ignition 3 Sided Gas Fireplaces ALL STRUCTURAL WORK TO ARCHITECTS DESIGN LOCATION REQUIREMENTS Openable window Refer note 3 Refer note 2 T = Flue Terminal M = Gas Meter Shading indicates prohibited I = Mechanical Inlet... -
Page 9: Gas Installation
Installation Instructions Kemlan Natural Draft Electronic Ignition 3 Sided Gas Fireplaces Gas Installation Laying the fire - Coal & Pebble 1. Check unit is suitable for intended gas supply. • Evenly spread a bag of Vermiculite into the burner 2. Note position on gas appliance on drawing specification tray. - Page 10 Installation Instructions Kemlan Natural Draft Electronic Ignition 3 Sided Gas Fireplaces Laying the fire - Coal & Pebble MARK 2 COALS 440 / 500 - 390 x 240 MARK 2 COALS 600 - 460 x 260 MARK 2 COALS 700 - 580 x 260...
-
Page 11: Commissioning Procedure
Installation Instructions Kemlan Natural Draft Electronic Ignition 3 Sided Gas Fireplaces Commissioning Procedure 2. Initially the Kemlan coal fire may burn with a slightly blue flame. After approximately 20 minutes the fire will settle down and burn with a yellow flame. - Page 12 SPARK ELECTRODE TECHRITE AUTOMATIC IGNITION SYSTEM CONTROLLER Wall Switch Flue Air Flow Air Flow Switch Switch For further service information contact Kemlan Australia Head Office: 13 French Avenue, Brendale Qld 4500 PH: (07) 3490 5500 FAX: (07) 3490 5520 www.kemlan.com...
- Page 13 3 SIDED ELEVATION WALL SWITCH ON/OFF SWITCH BURNER 240V PLUG 430x125mm AIR VENT TO AIR BURNER For further service information contact Kemlan Australia Head Office: 13 French Avenue, Brendale Qld 4500 PH: (07) 3490 5500 FAX: (07) 3490 5520 www.kemlan.com...
- Page 14 Head Office 13 French Avenue, Brendale Qld 4500 PH: (07) 3490 5500 FAX: (07) 3490 5520 www.kemlan.com For further service information contact Kemlan Australia Head Office: 13 French Avenue, Brendale Qld 4500 PH: (07) 3490 5500 FAX: (07) 3490 5520 www.kemlan.com...
