Page 2: Location Requirements
Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Power Flue approved for the Model Type 2: following models: Power Flue Decorative Gas Fireplace SUITABLE GAS BURNER OPTION SINGLE SIDED MODELS DATA PLATE: Refer to data plate for information in respect to gas pressure, consumption and gas type,... - Page 3 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Location Requirements Shading indicates prohibited I = Mechanical air inlet P = Electricity meter or fuse box areas for flue terminals Below eaves, balconies or other projections: MIN. CLEARANCE (mm) Appliances up to 50 MJ/h input ........................300 Appliances over 50 MJ/h input ..........................
-
Page 4: Before Installation
Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Before Installation Installation The Horizon powered flue system shall be installed by 1 Access must always be available to the fan system for authorized personnel in accordance with the servicing. If installing the internal fan system an manufacturer’s installation instructions, local gas fitting... - Page 5 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Measurement and Specifications of Fan Power Flue EXTERNAL FAN INTERNAL FAN DOUBLE SIDED - SIDE EXIT SINGLE SIDED - REAR EXIT 1010 1210 1010 1210 1010 1210 INTERNAL FAN CANTILEVER - REAR EXIT...
-
Page 6: Framing Dimensions
Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Framing Dimensions DOUBLE SIDED SINGLE SIDED *MAX HEIGHT BASED ON 2.4M CEILING Kelman Powered Flue External Fan Details WALL MOUNTED ROOFING MATERIAL FLASHING COVER CEILING OUTSIDE WALL SCALE 1:20 FLASHING COVER OUTER FLUE... - Page 7 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Section of Fan Power Flue INTERNAL EXTERNAL - REAR EXIT - REAR EXIT Elevation of Fan Power Flue INTERNAL FAN EXTERNAL FAN - SIDE EXIT - SIDE EXIT *220mm *300mm SINGLE SIDED ELEVATION CANTILEVER ELEVATION *MAX HEIGHT 22OMM BASED ON 2.4M CEILING...
-
Page 8: Gas Installation
Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Gas Installation Laying the fire - 1 Check unit is suitable for intended gas supply. Coal & Pebble 2 Note position on gas appliance on drawing • Evenly spread a bag of Vermiculite into the burner specification on right hand side of appliance. - Page 9 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire - Coal & Pebble MARK 2 COALS 440 / 500 - 390 X 240 MARK 2 COALS 600 - 460 X 260 MARK 2 COALS 700 - 580 X 260...
- Page 10 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire - 850 Ceramic Log P O S I T I O N I N G O F A L L L O G S • It is important to follow the log recommended positioning.
- Page 11 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire - 850 Ceramic Log 4. LOCATE LOG NO. 4. 6 . LO C ATE L O G N O. 9 . Place it on the left side of the This log is placed on the rear rear log.
- Page 12 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire - 700 Ceramic Log P O S I T I O N I N G O F A L L L O G S • It is important to follow the log This is the largest log that LO C ATE LO G N O.
- Page 13 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire - 700 Ceramic Log This log is placed with the The charred effect of the LOCATE LOG NO. 4. LOC ATE LOG N O. 7: log is positioned on the smaller coal in the centre of thinner edge on the smaller coal.
-
Page 14: Commissioning Procedure
Unit should cut out if not enough draw to ensure proper functioning. For further information contact Kemlan Australia Head Office: 59 Pineapple St Zillmere QLD 4034 Telephone 07 3263 8488 Facsimile 07 3263 6452 www.kemlan.com... - Page 15 Notes For further information contact Kemlan Australia Head Office: 59 Pineapple St Zillmere QLD 4034 Telephone 07 3263 8488 Facsimile 07 3263 6452 www.kemlan.com...
