  • Page 1 ---- ---- FIREPLACES Installation Instructions Power Flue Horizon Gas Fireplaces...
  • Page 2: Location Requirements

    Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Power Flue approved for the Model Type 2: Power Flue following models: Decorative Gas Fireplace SUITABLE GAS BURNER OPTION DATA PLATE: Refer to data plate for information in SINGLE SIDED MODELS respect to gas pressure, consumption and gas type, Natural or LPG.
  • Page 3 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces T = flue terminal Gas meter Shading indicates I = Mechanical air inlet P = Electricity meter prohibited fuse box areas for flue terminals Below eaves, balconies or other projections: MIN. CLEARANCE...
  • Page 4: Before Installation

    Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Installation Before Installation N.D.E.I. system supplied with The Natural Draft Electronic Ignition (N.D.E.I.) flue required electrical fittings. Work needs to be system shall be installed by authorized personnel in undertaken by a licensed electrician if extending accordance with the manufacturer’s installation...
  • Page 5 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Measurement and Specifications of Fan Power Flue EXTERNAL FAN INTERNAL FAN LIP FRAME DETAIL TYP. DOUBLE SIDED-SIDE EXIT SINGLE SIDED-REAR EXIT FRONT SHEETING PANEL INTERNAL FAN 3 PIN PLUG CASING ON/OFF SWITCH...
  • Page 6 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Power Flue with Internal Fan COOLING ROTOR INBUILT THERMAL OVERLOAD HEAT TRANSFER GAS COWL COOLING IMPELLER 6” x 900 8” x 900 12” x 900 SILENCER 12” x 200 VENTED FLUE REDUCER 7”...
  • Page 7 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Power Flue with External Fan 10MM GAP BETWEEN END OF FLUE TO WALL 2x 6” 45 DEG WALL MOUNTED 2x 8” 45 DEG 12” – 8” REDUCING CAP 6” x 900 8” x 900 12”...
  • Page 8: Framing Dimensions

    Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces FRAMING DIMENSIONS DOUBLE SIDED DOUBLE SIDED 700 LOW LINE 1056 1050 850 LOW LINE 1145 1145 1100 LOW LINE 1408 1145 1500 LOW LINE 1796 1280 2000 LOW LINE 2293 1280 * INCLUDING 10mm PLASTERBOARD C* - INTERNAL FRAME HEIGHT WHEN USING HEAT ZONE KIT.
  • Page 9 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces 300MM SECTIONS CLEARANCE TO EAVES * 75MM MIN. CLEARANCE TO TIMBER 75MM MIN. CLEARANCE TO TIMBER 25MM MIN. FLUE INTERNAL FAN CASING CLEARANCE TO TIMBER ACCESS PANEL FOR FAN SERVICE TO ARCHITECTS DETAIL...
  • Page 10: Gas Installation

    Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire – Gas Installation Coal & Pebble Check unit is suitable for intended gas supply. Note position on gas appliance on drawing specification on right hand side of appliance. • Evenly spread a bag of Vermiculite into the burner A gas cock has to be fitted prior to gas burner to allow tray.
  • Page 11 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire – Coal & Pebble MARK 2 COALS 700/800 – 600 X 155 MARK 2 PEBBLES 700/800 – 600 X 155 MARK 2 COALS 1000 – 992 X 135 MARK 2 PEBBLES 1000 – 992 X 135 MARK 2 COALS 1400 –...
  • Page 12 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire - 850 Ceramic Log P O S I T I O N I N G O F A L L L O G S • It is important to follow the log recommended 2 .
  • Page 13 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire - 850 Ceramic Log 4 . LOCATE LOG NO. 4. Place it on the left 6. LOCATEL O G N O. 9 . This log is placed on the log in the centre of the burner.
  • Page 14 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire – 700 Ceramic Log P O S I T I O N I N G OF A L L L O G S • It is important to follow the recommended positioning.
  • Page 15 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Laying the fire - 700 Ceramic Log 4 . LOC ATE LOG NO. 4. This log is placed 6 . L O C AT E L O G N O. 7 : The charred with the thinner edge on the smaller coal.
  • Page 16: Commissioning Procedure

    Should assistance be required contact nearest Warranty agent. E The gas burner is designed to work in a Kemlan Provided the appliance has been correctly Horizon electronic power flue ignition system. installed according to instructions, Kemlan guarantee Working correctly there will be no spillage.
  • Page 17: Wiring Diagram

    Wiring Diagram Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces For further service information contact Kemlan Australia Head Office –13 French Avenue, Brendale, Queensland 4500 Telephone –PH: (07) 3490 5500...
  • Page 18 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Service Instructions for Direct Ignition and Power Flue Horizon fireplaces. POWER FLUE SERVICE INSTRUCTIONS PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION PILOT WILL NOT LIGHT WITH FAN - CHECK FOR GAS SUPPLY AND TURN ON...
  • Page 19 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces DIRECT IGNITION PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION - CHECK FOR GAS SUPPLY AND TURN ON ALL CONNECTIONS PILOT WILL NOT LIGHT 1) NO GAS - CHECK GAS PRESSURE - CHECK PILOT AND CLEAN INJECTOR...
  • Page 20 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Trouble shooting guide for Techrite ignition pack Warning: This is a 240VAC module. All connections to the module are 240V (except ignition cable and flame sense). Ensure power is switched off before checking any connection or replacing any components.
  • Page 21 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces Flash Code Meaning Possible Cause (Red LED) Pressure switch fail Check combustion fan. Check unit has started and pressure switch and connections. during heat cycle the Check flue for obstructions pressure switch has...
  • Page 22 Installation Instructions Kemlan Power Flue Horizon Gas Fireplaces TAIS Flash Codes LED Flash Code Descriptions Flash Code (Long flashes– short Description flashes) Normal Start Up Operation Normal Running State Flame failure Waiting for pressure switch ON Waiting for pressure switch to go OFF...
