Specialists in fireplace design and manufacture
HALO 800 FREESTANDING HARDWOOD
INSTALLATION & OPERATING INSTRUCTIONS
IMPORTANT:
INSTALLER, PLEASE LEAVE THESE INSTRUCTIONS WITH THE UNIT ON COMPLETION.
10 YEAR FIREBOX WARRANTY
The firebox is covered by a 10 year warranty.
Other parts are covered by a one year limited warranty.
Head Office – 13 French Avenue, Brendale, Queensland 4500
Telephone – PH: (07) 3490 5500
Facsimile – FAX: (07) 3490 5520
Website: -
www.jetmaster.com.au
Business hours: - Monday to Thursday 7:30am-4:00pm. Friday 7:30am-2:00pm
Email: -
sales@jetmaster.com.au
24/07/2024
ver.5
1
Advertisement
Related Manuals for Kemlan HALO 800
Summary of Contents for Kemlan HALO 800
- Page 1 Specialists in fireplace design and manufacture HALO 800 FREESTANDING HARDWOOD INSTALLATION & OPERATING INSTRUCTIONS IMPORTANT: INSTALLER, PLEASE LEAVE THESE INSTRUCTIONS WITH THE UNIT ON COMPLETION. 10 YEAR FIREBOX WARRANTY The firebox is covered by a 10 year warranty. Other parts are covered by a one year limited warranty.
- Page 2 DIMENSIONS HALO 800 FREESTANDING HARDWOOD WITH FAN DESC. MODEL HALO 800 FS FREESTANDING HARDWOOD 24/07/2024 ver.5...
- Page 3 DIMENSIONS HALO 800 FREESTANDING HARDWOOD CLEARANCES Combustible walls *150 Parallel position 1095 1050 * The rear wall clearance can be 150mm from a combustible wall when installed with an additional 900mm high x 180 deg. stainless steel rear flue shield.. The rear flue shield must cover the rear of the spigot. The...
- Page 4 HALO 800 HARDWOOD FREESTANDING MERIDIAN BENCH MEASUREMENTS TOP VIEW SIDE VIEW FRONT VIEW 24/07/2024 ver.5...
- Page 5 HEATSHIELD CAN BE USED FROM IMPORTANT: ANY APPENDIX F 900MM UP TO 1200MM HEIGHT” APPROVED FLUE KITS CAN BE USED ON THESE KEMLAN “THIS HEATER HAS BEEN TESTED WITH FREESTANDING FIREPLACES AS THE FAN CONNECTED TO A STANDARD LONG AS IT COMPLIES WITH THE 3 PIN GPO SOCKET OUTLET.
- Page 6 FREESTANDING FLUE KIT ( APPENDIX F) 2 – 6” STAINLESS STEEL FLUE 1000mm CRIMPED 2 - 6” STAINLESS STEEL FLUE 1000mm CRIMPED, BLACK 1 – 8” GALVANISED FLUE 1000mm PLAIN 1 – 8” GALVANISED FLUE 1000mm CRIMPED 1 – 10” GALVANISED FLUE 1000mm PLAIN 1 - 10”...
- Page 7 FREESTANDING UNIT WITH HEAT SHIELD ( DECRO 8”) VENTED CAP HEAT SHIELD 8” DECRO HEAT SHIELD 24/07/2024 ver.5...
- Page 8 FREESTANDING DECRO FLUE KIT 3 – 6” STAINLESS STEEL FLUE 1000mm CRIMPED 1 – 6” STAINLESS STEEL FLUE 1000mm CRIMPED/SWAGED 2 – 8” GALVANISED FLUE 1000mm PLAIN/CRIMPED 1 – 10” GALVANISED FLUE 1000mm PLAIN 1 - 10” DROP BOX, 8”-10” VENTED CAP, CRIMPED, BLACK 1 –...
- Page 9 HALO 800 HARDWOOD BAFFLE PLATE / AIR TUBE INSTALLATION INSTRUCTION 1. Install the first air tube by pushing it 2. All air tube holes must point to sides and up, over and into the air tube holders. bottom of the appliance. Push the air tube Make sure the air tube end with no cap as far back as possible.
- Page 10 HALO 800 FAN ASSEMBLY INSTALLATION INSTRUCTION 1. Break the tabs on the rear panel where indicated. Use a flat-head screwdriver to aid in breaking tabs if required and twist panel until the tabs are broken. Remove the panel from the box. Unscrew the Tek screws and set aside for re-use.
-
Page 11: Installation Instructions
INSTALLATION INSTRUCTIONS MINIMUM HEIGHT OF FLUE SYSTEM EXIT INSTALLATION TO COMPLY WITH AS/NZS 2918 ANY NEARBY STRUCTURE 6000 3000 OR LESS MORE THAN 3000 600 MIN 3000 INCREASE AS NECESSARY UNTIL NOTHING WITHIN 3000 OF FLUE TOP 1000 MIN IF CLEAR WITHIN 3000 OF TOP OF FLUE 3000 OR LESS 3000... -
Page 12: Installation Instruction
INSTALLATION INSTRUCTION HALO 800 FLAT CEILING INSTALLATION Run a bead of silicone down the vertical seam of the outer casing to the flashing Pop rivet or Bracing supplied by installer Short tube fits into flue screw brackets to pipe. All flues should... - Page 13 INSTALLATION INSTRUCTION HALO 800 RAKED CEILING INSTALLATION Run a bead of silicone down Short tube fits into flue the vertical seam of the outer pipe. All flues should casing to the flashing Pop rivet or be trimmed level screw brackets to...
- Page 14 The third goal of the initial burns is to cure the paint on the fireplace casing, Kemlan fires are painted with a high- temperature paint.
- Page 15 Please take some time to watch to see if your process is the same. Now your Kemlan fire is up and running make sure to keep the primary air slide fully open, this will ensure maximum oxygen is getting to the fuel and this will create quicker heat into the fireplace box, baffle, flue, and of course your home.
- Page 16 The black creosote will burn off the glass when the fire’s air control is back up to high with a new load of timber. If you follow these simple steps, you will find your Kemlan fireplace is one of the best investments you have made to your home.
-
Page 17: This Warranty Does Not Cover
4.9 Cost of inspection for damaged heater. CLAIMS – 5.1 (I) Kemlan will provide a full replacement of the heater in the first five years after installation. (ii) Replacement in the subsequent five years (i.e. sixth to tenth year after installation will be on the following basis. - Page 18 NOTES 24/07/2024 ver.5...
