Specialists in fireplace design and manufacture
CELESTIAL 900 FREESTANDING SOFTWOOD
INSTALLATION & OPERATING INSTRUCTIONS
IMPORTANT:
INSTALLER, PLEASE LEAVE THESE INSTRUCTIONS WITH THE UNIT ON COMPLETION.
10 YEAR FIREBOX WARRANTY
The firebox is covered by a 10 year warranty.
Other parts are covered by a one year limited warranty.
Head Office – 13 French Avenue, Brendale, Queensland 4500
Telephone – PH: (07) 3490 5500
Facsimile – FAX: (07) 3490 5520
Website: -
www.jetmaster.com.au
Business hours: - Monday to Thursday 7:30am-4:00pm. Friday 7:30am-2:00pm
Email: -
sales@jetmaster.com.au
24/07/2024
Ver.17
1
Advertisement
Related Manuals for Kemlan CELESTIAL 900 FREESTANDING SOFTWOOD
Summary of Contents for Kemlan CELESTIAL 900 FREESTANDING SOFTWOOD
- Page 1 Specialists in fireplace design and manufacture CELESTIAL 900 FREESTANDING SOFTWOOD INSTALLATION & OPERATING INSTRUCTIONS IMPORTANT: INSTALLER, PLEASE LEAVE THESE INSTRUCTIONS WITH THE UNIT ON COMPLETION. 10 YEAR FIREBOX WARRANTY The firebox is covered by a 10 year warranty. Other parts are covered by a one year limited warranty.
- Page 2 THE FIRST LENGTH OF 8” DECRO FROM THE UNIT MUST HAVE DOUBLE HEAT SHIELD IMPORTANT: ANY APPENDIX F APPROVED FLUE ON THESE KEMLAN KITS CAN BE USED FREESTANDING FIREPLACES AS LONG AS IT COMPLIES WITH THE LABORATORY TESTED HEAT SHIELDING”...
- Page 3 MINIMUM CLEARANCES FOR THE CELESTIAL 900 FREESTANDING SOLID FUEL APPLIANCE INSTALLED WITH DEFAULT FLUE KIT COMBUSTIBLE WALL COMBUSTIBLE WALL MINIMUM CLEARANCES: MEASUREMENT 45** 1051 1180 1401 460* NOTE: *As per Clause 3.3.2 of AS/NZS 2918:2001 for floor protector construction requirements. This measurement only applies when The floor protector consists of an 18mm thick Bellis Board or similar unit is 200mm above floor.
- Page 4 HEARTH MEASUREMENT CELESTIAL 900 FREESTANDING A MINIMUM 18MM UNIT THICK FLOOR PROTECTOR SHOULD BE USED UNDER THE APPLIANCE. A MINIMUM 18mm NON COMBUSTIBLE MATERIAL FC SHEET OR SIMILAR CAN BE USED IN FRONT OF THE APPLIANCE UNIT HEIGHT ABOVE FLOOR HEARTH DIMENSION FORWARD OF UNIT 24/07/2024 Ver.17...
- Page 5 HEARTH REQUIREMENTS FOR INSTALLATION ONTO A RAISED HEARTH A MINIMUM 18MM THICK FLOOR CELESTIAL 900 PROTECTOR SHOULD BE USED FREESTANDING UNDER THE UNIT A MINIMUM 18mm NON APPLIANCE. COMBUSTIBLE MATERIAL FC SHEET OR SIMILAR CAN BE USED IN FRONT OF THE APPLIANCE MIN.
- Page 6 MINIMUM REQUIREMENTS FOR INSTALLATION ON A STEEL TABLE CELESTIAL 900 UNIT METAL TABLE * NOTE: NO FC SHEETING UNDER THE APPLIANCE IS REQUIRED FOR THIS ASSEMBLY. 24/07/2024 Ver.17...
- Page 7 BAFFLE PLATE INSTALLATION 1. REMOVE MIDDLE AIR TUBE BY PUSHING 2. PLACE ALL 4 BAFFLE PLATES ABOVE AIR TUBES UP AND REMOVING FROM FRONT AND BOTH SIDES CLOSEST TO THE FIRE BOX WALL REAR BRACKETS. AS SHOWN ( 2 LEFT AND 2 RIGHT) 3.
- Page 8 CELESTIAL 900 DOOR ADJUSTMENT INFORMATION MARK THE POSITION OF THE ADJUSTMENT OPEN THE DOOR AS FAR AS REQUIRED, AND ANGLE ON THE FIREBOX. IT IS CRITICAL TO THE ADJUSTMENT ANGLE IS ACCESSIBLE. PUT THE ADJUSTMENT ANGLE AT THE SAME SPOT. SO THAT THE DOOR WILL LOCK PROPERLY.
- Page 9 SEISMIC RESTRAINTS MERIDIAN BASE INSTALLATION Locate and align the holes on the underside Place the appliance on top of the meridian base. of the appliance and top of the meridian Make sure to align the front and side edges of base.
- Page 10 SEISMIC RESTRAINTS TABLE INSTALLATION Tek screws Place the back of the appliance aligned to the Attach the supplied bracket by locating the holes back edge of the cube table. Make sure the in the appliance and table on both sides as appliance is centred from the left and right edges.
- Page 11 IMPORTANT: ANY APPENDIX F HEATSHIELD CAN BE USED FROM APPROVED FLUE KITS CAN BE 900MM UP TO 1200MM HEIGHT” USED ON THESE KEMLAN FREESTANDING FIREPLACES AS “THIS HEATER HAS BEEN TESTED WITH LONG AS IT COMPLIES WITH THE THE FAN CONNECTED TO A STANDARD LABORATORY TESTED HEAT 3 PIN GPO SOCKET OUTLET.
- Page 12 FREESTANDING FLUE KIT ( APPENDIX F) 2 – 6” STAINLESS STEEL FLUE 1000mm CRIMPED 2 - 6” STAINLESS STEEL FLUE 1000mm CRIMPED, BLACK 1 – 8” GALVANISED FLUE 1000mm PLAIN 1 – 8” GALVANISED FLUE 1000mm CRIMPED 1 – 10” GALVANISED FLUE 1000mm PLAIN 1 - 10”...
- Page 13 FREESTANDING UNIT WITH HEAT SHIELD ( DECRO 8”) HEAT SHIELD VENTED CAP HEAT SHIELD 8” DECRO 24/07/2024 Ver.17...
- Page 14 FREESTANDING DECRO FLUE KIT 3 – 6” STAINLESS STEEL FLUE 1000mm CRIMPED 1 – 6” STAINLESS STEEL FLUE 1000mm CRIMPED/SWAGED 2 – 8” GALVANISED FLUE 1000mm PLAIN/CRIMPED 1 – 10” GALVANISED FLUE 1000mm PLAIN 1 - 10” DROP BOX, 8”-10” VENTED CAP, CRIMPED, BLACK 1 –...
- Page 15 SINGLE HEATSHIELD INSTALLATION INFORMATION FOR FLAT CEILING STAINLESS STEEL DOUBLE CONE COWL RUN A BEAD OF SILICONE DOWN THE VERTICAL SEAM OF THE OUTER CASING TO THE FLASHING SHORT TUBE FROM SUPPORT OUTER FLUE THE COWL FITS WITH ANGLE BRACKET INTO FLUE PIPE.
- Page 16 SINGLE HEATSHIELD INSTALLATION INFORMATION FOR RAKED CEILING STAINLESS STEEL DOUBLE RUN A BEAD OF SILICONE DOWN CONE COWL THE VERTICAL SEAM OF THE OUTER CASING TO THE FLASHING SHORT TUBE FROM ALL CASING FLUE THE COWL FITS PIPES INTO FLUE PIPE. MUST BE CONNECTED FLUES SHOULD BE VIA POP RIVETS...
- Page 17 INSTALLER. DECRO E (NO VENTED CAP NO CRIMP, IMPORTANT: ANY APPENDIX F APPROVED FLUE NO HEATSHIELD) ON THESE KEMLAN KITS CAN BE USED HEAT SHIELD FREESTANDING FIREPLACES AS LONG AS IT COMPLIES WITH THE LABORATORY TESTED HEAT SHIELDING” DECRO A (WITH HEATSHIELD) INSTALL THE NEXT LENGTH OF DECRO.
- Page 18 ALL 8”-10” ASSEMBLED FLUES IMPORTANT: ANY APPENDIX F MUST HAVE THE CRIMPS MUST HAVE THE CRIMPS APPROVED FLUE KITS CAN BE POINTING DOWNWARDS POINTING UPWARDS ON THESE KEMLAN USED THE FIRST LENGTH DETAIL D FREESTANDING FIREPLACES DETAIL C OF 8” DECRO FROM...
- Page 19 ALL 8”-10” ASSEMBLED FLUES MUST HAVE THE CRIMPS MUST HAVE THE CRIMPS IMPORTANT: ANY APPENDIX F POINTING DOWNWARDS POINTING UPWARDS APPROVED FLUE KITS CAN BE ON THESE KEMLAN USED DETAIL D DETAIL C THE FIRST LENGTH FREESTANDING FIREPLACES OF 8” DECRO FROM...
- Page 20 CELESTIAL 900 BOOST OPERATION BOOST FLAP, IN OPEN POSITION. PUSHED TOWARDS THE RIGHT AS FAR AS POSSIBLE. NOTE: The boost flap need to be left open for the first 20 minutes of operation, in order to light the fire better. After this time, normal appliance operation will commence and the boost flap will need to be shut for the duration of use.
-
Page 21: Installation Instructions
INSTALLATION INSTRUCTIONS MINIMUM HEIGHT OF FLUE SYSTEM EXIT INSTALLATION TO COMPLY WITH AS/NZS 2918 ANY NEARBY STRUCTURE 3000 MORE THAN 6000 3000 OR LESS 3000 INCREASE AS NECESSARY UNTIL 1000 MIN IF CLEAR WITHIN NOTHING WITHIN 6000 OF THE FLUE 3000 OF TOP OF FLUE 3000 OR LESS... - Page 22 24/07/2024 Ver.17...
- Page 23 The third goal of the initial burns is to cure the paint on the fireplace casing, Kemlan fires are painted with a high- temperature paint.
- Page 24 Please take some time to watch to see if your process is the same. Now your Kemlan fire is up and running make sure to keep the primary air slide fully open, this will ensure maximum oxygen is getting to the fuel and this will create quicker heat into the fireplace box, baffle, flue, and of course your home.
- Page 25 ‘full left’ introducing maximum primary air again. If you follow these simple steps, you will find your Kemlan fireplace is one of the best investments you have made to your home.
-
Page 26: This Warranty Does Not Cover
4.9 Cost of inspection for damaged heater. CLAIMS – 5.1 (I) Kemlan will provide a full replacement of the heater in the first five years after installation. (ii) Replacement in the subsequent five years (i.e. sixth to tenth year after installation will be on the following basis.
